Автоматическая герметизация робота из стекла и
- Категория: Оборудование для производства стеклянных изделий >>>
- Поставщик: Jinan,Glasino,Glass,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.43 $* | 0.20 $* |
| Aug-18-2025 | 0.51 $* | 0.88 $* |
| Jul-18-2025 | 0.49 $* | 0.80 $* |
| Jun-18-2025 | 0.52 $* | 0.39 $* |
| May-18-2025 | 0.62 $* | 0.91 $* |
| Apr-18-2025 | 0.9 $* | 0.72 $* |
| Mar-18-2025 | 0.53 $* | 0.2 $* |
| Feb-18-2025 | 0.61 $* | 0.23 $* |
| Jan-18-2025 | 0.79 $* | 0.88 $* |
Характеристики
Product Description
Quick Details
Condition: New
Brand Name: Glasino
Power(W): 7Kw
Weight: 3500kg
Warranty: 1YEAR
Min Glass Size: 300*300mm
Machine Type: Insulating Glass Production Line
Place of Origin: Shandong,China
Voltage: 380V
Dimension(L*W*H): 8030*1400*2950
Certification: CE
Color： Blue
Supply Ability
Supply Ability:30 Unit/Units per Month
Brief Introduction:
1. Integrated frame design in order to minimize the size of equipment, saving installation space.
2. Automatic sealant discharging function to avoid the pipe blockage caused by human factors.
3. Special design for checking the depth of sealant in order to control the spread of sealant automatically.
4. Two sets of spreading sealant system can work completely independent(including mixer). One key switch for changing two
component sealant.
5. Coating with glass edge neatly, no dislocation. After coating the glass edge without seam, enrich the corner, quadrilateral
smooth surface no need to repair the glass corner.
6. V block type synchronous belt, make sure the smooth glass transmission and accurate position-ing, also can reduce the
phenomenon of belt sticking by sealant.
7. Convenient operation.
2. Automatic sealant discharging function to avoid the pipe blockage caused by human factors.
3. Special design for checking the depth of sealant in order to control the spread of sealant automatically.
4. Two sets of spreading sealant system can work completely independent(including mixer). One key switch for changing two
component sealant.
5. Coating with glass edge neatly, no dislocation. After coating the glass edge without seam, enrich the corner, quadrilateral
smooth surface no need to repair the glass corner.
6. V block type synchronous belt, make sure the smooth glass transmission and accurate position-ing, also can reduce the
phenomenon of belt sticking by sealant.
7. Convenient operation.
Detailed Images
We work with everything from raw material to final machine, could guarantee machine quality from each step. select each part carefully, we are strive to quality first when machine production and test each machine before delivery.
We will provide the best machine for you.
We will provide the best machine for you.
Main parts
Name | Brand | Place of Origin |
Head rotating servo motor | YASKAWA | Japan |
Sealant nozzle servo motor | YASKAWA | Japan |
Head up/down servo motor | YASKAWA | Japan |
Sucker servo motor | YASKAWA | Japan |
Transport servo motor | YASKAWA | Japan |
PLC controller | YASKAWA | Japan |
IO module | MAYSTEM | Japan |
Sensor | Autonics | South Korea |
All low voltage appliance | Schneider | France |
Cylinder | Airtac | Taiwan |
Position sensor of belt | Novotechnik | Germany |
Size Information
Model | Max Glass Size | Min Glass Size | Glass Thickness | Work Soeed | Overall Dimension |
ZNJ2025 | 2000*2500mm | 300*300mm | 12-56mm | 5-40 m/min | 8030*1400*2950mm |
ZNJ2540 | 2500*4000mm | 300*300mm | 12-56mm | 5-40 m/min | 8630*1400*3500mm |
Packing&Shipping
Customer Photos
Company Introduction
Jinan Glasino Technology Co, Ltd founded in 2003, is the high-tech enterprises specializing in the production of CNC glass cutting machine, insulating glass machine, curtain wall glass machine, market share ranks first in the same line. Main products are: Laminated glass cutting machine, Automatic glass cutting line, Multifunctional glass cutting machine,Insulating glass production line, Automatic insulating glass CNC sealing machine, Aluminum spacer bending machine, Desiccant filling machine etc, full set processing machines for insulating glass. We have passed European CEcertificate, Switzerland SGS certificate, ISO 9001: 2008 quality control system, win good reputation from domestic and international customer.
Outstanding quality is the basis of brand.Satisfying service is the guarantee or brand. Perpetual innovation is the soul of brand.
Glasino people will continue making efforts and persist in taking the quality as the life of the enterprise. Continuously improve the production management level, research and develop more advanced tecnology to meet the needs of the market. Glasino will work with you to create a brilliant future.
Related Products
FAQ
1. Q: are you a manufacturer?
A: yes, we have been offering specialized products in this field for many years.
2.Q: how do I install this machine?
A:We will send engineers to the site for installation, debugging and training
3. Q: how do you pack these products?
A: usually packed according to export standard or your requirement.
4. Q: is it customizable?
A: yes, according to the detailed drawings you provided
5.Q: after-sales service
24-hour technical support by phone, email or skype.
6.Q: what is your lead time?
A: it usually takes 15-30 days for A single pot, and 30-50 days for the whole plant.
7. Do you have CE?
A: yes.
A: yes, we have been offering specialized products in this field for many years.
2.Q: how do I install this machine?
A:We will send engineers to the site for installation, debugging and training
3. Q: how do you pack these products?
A: usually packed according to export standard or your requirement.
4. Q: is it customizable?
A: yes, according to the detailed drawings you provided
5.Q: after-sales service
24-hour technical support by phone, email or skype.
6.Q: what is your lead time?
A: it usually takes 15-30 days for A single pot, and 30-50 days for the whole plant.
7. Do you have CE?
A: yes.
