Батарейный блок 9VBS450/48V450Ah для тягового вилочного погрузчика серия 158 VBS с поворотной трубкой или системой
- Категория: Battery Packs >>>
- Поставщик: Guangzhou,CBB,Battery,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.14 $* | 0.96 $* |
| Aug-15-2025 | 0.35 $* | 0.93 $* |
| Jul-15-2025 | 0.77 $* | 0.90 $* |
| Jun-15-2025 | 0.60 $* | 0.53 $* |
| May-15-2025 | 0.42 $* | 0.96 $* |
| Apr-15-2025 | 0.62 $* | 0.75 $* |
| Mar-15-2025 | 0.86 $* | 0.52 $* |
| Feb-15-2025 | 0.6 $* | 0.12 $* |
| Jan-15-2025 | 0.96 $* | 0.80 $* |
Характеристики
CBB Battery Technology Co., Ltd
CBB Battery offers complete battery solutions for all of the motive power applications found below. Each battery line is designed for the unique demands of each application.
Product Description
LIFT TRUCK / FORKLIFT BATTERIES
motive power batteries delivers uninterrupted performance for lift truck operators, and big cost savings for your business.
--------------------
Specification:
Heavy duty power Products name: forklift battery
Capacity:450ah
Nominal Voltage:48V
type: VBS type
Steel box size: 1000*700*500mm
Single cell size: 157*158*385*420mm
Connector: Flexible connector/soft connector
Weight: 18kgs dry weight, 25kgs wet weight for each cell
Specail design: with autofilling system/ with diversion tube
OEMavailable
No.of.terminal:2
Material of container: PP
Certificate: ISO,CE, SGS,UL
Certificate: ISO,CE, SGS,UL
material:lead acidcompany
located in: Guangdong
Application:
Electric forklift;
Electric trasporting cars;
Electric stacker cars;
Electric pallet trucks;
Tunnel/metro locomotives;
Road vehicles and other deep cycle DC power supply equipment;
Product Features:
1.158 series and 188 series cells.
2.Robust,flooded tubular technology.
3.Highest standards of design,materials and workmanship.
4.Outstanding deep cycling capacity & reliability.
5.Spines of antimonial lead filled with lead oxide and less maintenance.
Advantage:
1. Tubular positive plates and pasted negative plates
2. Low Self-discharge and Low Energy Cost
3. Avoidance of insufficient discharging and over charging
4. Deep Cycle Performance
5. Long Service Life
After-sales service:
Note:
1), Please kindly use the forklift battery according to Seawill operation manual, do not over charge or over discharge the
battery, or not charge the forklift battery enough, please charge the battery in constant current every month, otherwise it would
reduce the battery's capacity and shorter battery's cycle life.
2), Please check battery's level every week, the professional engineer or worker is needed in the checking. Please make sure the
battery's electrolyte is not lower than the Minimum level, otherwise it would cause the battery's over heat and burn out.
3), Filling water must use the proper forklift battery water, if mix the impurity,it would cause battery's self discharge, over
heat or even poison gas, please not do not fill the water too excessive, and please keep battery's surface to be clean and dry,
otherwise, it would cause battery's electrolyte lead out and short circuit and etc problem.
24V3PZS240
24V3VBS210
48V750Ah
5VBS500-48V500AH
5VBS300-24V300Ah
3VBS210-24V200Ah
----forlift/traction Batteries Technical Specifications:
8VBS470-48V470AH
9PZS630-48V630AH
--------------------
2. TUBULAR DEEP-CYCLE FLOODED BATTERIESCBB’s Tubular deep-cycle flooded batteries (Trojan Batteries) are the traditional batteries for motive power, engineered to provide rugged durability, outstanding performance and long life, CBB ’s deep-cycle flooded batteries are perfectly suited for use in a variety of golf and electric vehicles. These powerful deep-cycle flooded batteries feature CBB’s historically-proven engineering and tubular plate technology, an advanced battery technology for maximum sustained performance, longer life and increased total energy.
----TUBULAR DEEP-CYCLE FLOODED BATTERIES Technical Specifications:
--------------------
3. ELECTRIC VEHICLES BATTERIESCBB DZM & EVF Series VRLA Gel Battery is specially designed for motive power applications, i.e. electric bikes/scooters, electric tricycles, electric motorcycles and others device require DC power source. The DZM Series adopts international leading technologies to ensure the batteries with features of long cycle life, large current discharge capability, high reliability and safety, and environmental-friendly.
CONTACT:
If you need more details or recommendations on the deep cycle batteries, please kindly feel free to contact
Judy Huang by mobile / Whats-App: + 86 186 2057 8581 wechat: judyhuang2014
or email: export1@cbb-battery.com
or email: export1@cbb-battery.com
Model No | Volts | Capacity | Length | Width | Height | Total Height | Weight | Terminal | ||||||||
V | Ah | mm | mm | mm | mm | kg | Type | |||||||||
DZM SERIES ELECTRIC VEHICLE BATTERY | ||||||||||||||||
6-DZM-12 | 12 | 12/5HR | 152 | 99 | 98 | 101 | 4.4 | F2 | ||||||||
8-DZM-14 | 16 | 14/5HR | 201 | 113 | 99 | 102 | 6.5 | F4 | ||||||||
6-DZM-20 | 12 | 20/5HR | 181 | 77 | 170 | 171 | 7 | T1 | ||||||||
6-DZM-24 | 12 | 24/5HR | 175 | 165 | 126 | 126 | 9 | T2 | ||||||||
6-DZM-28 | 12 | 28/5HR | 318 | 80 | 126 | 126 | 9.6 | T3 | ||||||||
6-DZM-30 | 12 | 30/5HR | 224 | 95 | 175 | 175 | 10.1 | T3 | ||||||||
6-DZM-35 | 12 | 35/5HR | 225 | 107 | 175 | 175 | 12 | T3 | ||||||||
6-DZM-42 | 12 | 42/5HR | 224 | 120 | 175 | 175 | 12.5 | T3 | ||||||||
6-DZM-50 | 12 | 50/5HR | 224 | 120 | 175 | 175 | 13.5 | T3 | ||||||||
EVF SERIES ELECTRIC VEHICLE BATTERY | ||||||||||||||||
3-EVF-200 | 6 | 200/3HR | 260 | 180 | 265 | 272 | 35 | T5 | ||||||||
4-EVF-150 | 6 | 150/3HR | 260 | 180 | 280 | 280 | 36.5 | T5 | ||||||||
6-EVF-40 | 12 | 40/3HR | 198 | 166 | 174 | 174 | 14.5 | T3 | ||||||||
6-EVF-80 | 12 | 80/3HR | 260 | 169 | 211 | 215 | 26.5 | T3 | ||||||||
6-EVF-100 | 12 | 100/3HR | 327 | 172 | 216 | 224 | 34.5 | T4 | ||||||||
6-EVF-120 | 12 | 120/3HR | 407 | 173 | 210 | 233 | 42 | T5 | ||||||||
6-EVF-135 | 12 | 135/3HR | 341 | 173 | 283 | 288 | 47 | T5 | ||||||||
6-EVF-150 | 12 | 150/3HR | 484 | 171 | 241 | 241 | 51 | T4 | ||||||||
6-EVF-200 | 12 | 200/3HR | 521 | 238 | 217 | 222 | 64 | T4 | ||||||||
Model No | Volts | Capacity | Max. Outer Dimension (mm) | Width | Height | Total Height | Max. Weight (KGS) | |||||||||
V | AH/5HR | Length | Width | Height | Total Height | Dry | With Acid | |||||||||
TUBULAR DEEP-CYCLE FLOODED VEHICLE BATTERY | ||||||||||||||||
3-DG-300 | 6 | 240 | 365 | 175 | 275 | 285 | 27.5 | 37 | ||||||||
6-DG-200 | 12 | 120 | 365 | 175 | 275 | 285 | 27.5 | 37 | ||||||||
6-DG-185 | 12 | 110 | 365 | 175 | 275 | 285 | 26 | 35 | ||||||||
6-DG-175 | 12 | 100 | 365 | 175 | 255 | 275 | 24.5 | 33 | ||||||||
6-DG-165 | 12 | 90 | 365 | 175 | 235 | 255 | 22 | 31 | ||||||||
6-DG-155 | 12 | 80 | 365 | 175 | 235 | 255 | 19 | 29 | ||||||||
6-DG-145 | 12 | 70 | 365 | 175 | 235 | 255 | 18 | 28 | ||||||||
6-DG-60 | 12 | 60 | 260 | 215 | 225 | 240 | 14.5 | 21 | ||||||||
6-DG-210 | 12 | 167 | 518 | 277 | 222 | 245 | 42 | 61 | ||||||||
6-DG-220 | 12 | 175 | 518 | 277 | 222 | 245 | 44 | 63 | ||||||||
6-DG-240 | 12 | 190 | 518 | 277 | 222 | 245 | 46.5 | 65.5 | ||||||||
6-EVF-200-12V200AH
6-EVF-120-12V120AH
6-EVF-75-12V75AH
For any detailed information, services or rates, please feel free contact us any time while visiting www.cbb-battery.com
Details Images
Packing & Delivery
Certifications
Company Profile
CBB Battery Technology Co., Ltd. is a large modern comprehensive power enterprise, specializing in proudction, R&D and sales of the full line of lead acid battery, with a factory area of 65 mu and production area more than 30000m2.
We mainly produce VRLA battery, automotive battery, motorcycle battery, motive power battery, tricycle battery, electric vehicle battery and various plates thereof. All batteries are widely used in UPS, Power station, solar power system, telecommunication, vehicles, boats, motorcycle and other applications.
