Характеристики
5L-1000L Continuous Stirred Tank Bio Stainless Steel Fixed Bed Chemical Reactor
Product Description
Stainless steel reactor has the characteristics of rapid heating, high temperature resistance, corrosion resistance, sanitation, no environmental pollution, no automatic heating of boiler, convenient use, etc. it is widely used in petroleum, chemical industry, rubber, pesticide, dye, medicine, food, to complete vulcanization, nitrification, hydrogenation, alkylation, polymerization, condensation and other process processes. It is based on the full mixing of reaction substances, For the physical change processes such as heating, cooling, liquid extraction and gas absorption, a stirring device is required to obtain good results, and the outer coil reactor can be designed and processed for customers.
Specifications
Capacity | 3L | 5L | 10L | 20L | 30L | 50L | 100L | 200L | 300L | 500L | 1000L | |
Material | Inner bladder: 304/316 optional, outer layer: 304/316 optional (Part of the contact material can be all designed as 316 material, strong acid-base products, can be installed as required high borosilicate glass liquid hopper or glass condenser) | |||||||||||
Electrothermal power(According to product design) | 1KW | 2KW | 3KW | 4KW | 5KW | 6KW | 12KW | 15KW | 18KW | 22KW | 25KW | |
Motor power | 0.12KW | 0.12KW | 0.18KW | 0.18KW | 0.18KW | 0.25KW | 0.75KW | 1.1KW | 1.5KW | 2.2KW | 3KW | |
Inner pan size | Can be customized according to requirements | 350 450 | 500 500 | 550 650 | 650 750 | 700 900 | 1050 1100 | |||||
Thickness of kettle body | 3mm 4mm 5mm 7mm Optional on demand | |||||||||||
Stirring speed | Constant speed 30-60r/min ,Speed regulation 50~500r/min ,Subsequent customization is require according to that state of the reaction medium | |||||||||||
Speed control mode | 1. Constant speed(30-60r/min) 2. Variable frequency speed regulation(50-300r/min)Speed adjustable (optional) | |||||||||||
Connection Mode | Butt weld flange type (kettle body opening is flange type) | |||||||||||
Sealing method | Mechanical seal/packing seal, can be designed and manufactured according to requirements | |||||||||||
Heating mode | Electric/steam/external circulate oil heating/external cryogenic cool circulating device | |||||||||||
Matching products(Match according to needs) | 1. Low temperature chiller | |||||||||||
Configuration | 1) Standard: Large flange/control box/mirror/connectable/cleaning ball/hand hole (solid feeding)/spotlight/ 2) Optional: feeding tank (stainless steel / glass optional) / liquid level meter / condenser / reflux collection / pH value monitoring or control / frequency conversion control 1) Selection: 1. Hydraulic lifting 2. Automatic PLC control system 2) Selection: 1. Disperser 2. Homogeneous shear 3. Emulsifying device | |||||||||||
The reactor is a customized product. The configuration of different process parameters will be different. The standard price is different from the optional price. We will customize the parameters and prices according to the needs of customers. Please contact customer service if necessary.
CE certification
Related Products
Company Profile
Packaging & Shipping
FAQ
Where's your company? How do I get to your company?
Our company is located in Building A3, Dongtai Founder Industrial Park, No. 78 Luntou Road, Haizhu District, Guangzhou City, Guangdong Province, China. You can fly to Guangzhou Baiyun International Airport, and then we will arrange a special person to pick you up.
Are you a what type company?
We are an innovative enterprise integrating processing, manufacturing and trade.
What kind of service does it offer?
We can provide customers with common laboratory equipment and equipment and pharmaceutical, chemical industry applications of reactor tanks and supporting temperature control equipment.
How strong is your company?
Our company was founded in 2006, has its own leading brand in the country, our products sell well in China, covering most of the laboratories, deeply loved and praised by users. We have many cooperative production bases in different cities in China, concentrating the best production resources and providing the best quality products. We design a wide range of products, we have professional technical engineers, can provide customers with solution design, product customization services.
How about the quality of your products?
Product quality is not only a customer concern, but also our most important issue! We even the importance of product quality, the company has set up a strict testing system, only after strict performance testing of products, issued testing certificates can be allowed to leave the factory, you can rest assured to buy.
