Машина для производства гофрированных картонных коробок
- Категория: Штамповысекальная машина для печати и прорезки на картоне >>>
- Поставщик: Dongguang,Ruichang,Carton,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 15470.15 $* | 16244.64 $* |
| Aug-18-2025 | 15340.19 $* | 16107.10 $* |
| Jul-18-2025 | 12870.1 $* | 13514.31 $* |
| Jun-18-2025 | 15080.2 $* | 15834.33 $* |
| May-18-2025 | 13130.19 $* | 13787.4 $* |
| Apr-18-2025 | 14820.8 $* | 15561.33 $* |
| Mar-18-2025 | 14690.36 $* | 15425.58 $* |
| Feb-18-2025 | 14560.11 $* | 15288.39 $* |
| Jan-18-2025 | 14430.17 $* | 15152.3 $* |
Характеристики
Product Description
Machine details
1.Feeding unit
•Chain feed type, double side baffle, high feeding precision and run steadily.
•Chain paper feeder and main machine forms lineal-speed differential, back baffle open the distance after finishing feeding paperboard and will not damage paperboard.
2.Printing unit
Static and dynamic correcting and drilling balancing, run steadily.
•Space between printing and pressing roller adjusted by worm gear,dial gauge display numerical value, adjustable range 1-11mm.
•Pneumatic lifting roller, prevent printing plate repeat inking and ink dry up when machine short time stopping.
•Adopt LCD computer phase control instrument, makes operation more convenient and accuracy.
•Pneumatic Diaphragm Pump, supply ink steady, operation and maintain easily.
•Manual type axial adjustment structure, ±5mm.
3.Slotting unit
Three unit for slotting,one unit for angle cutting,two unit for paper dividing and four unit for creasing.
•Creasing roller space manual adjustment, adjustable range: 0-12mm
•The width of slotting knives: 7mm
•Trimming knife is made up of Alloy steel, heat treatment, grinded. Sharp, high precision
slotting height adjustment adopt four knife synchro control, electrical horizontal adjustment.
•Slotting unit control pannel equipped with inching button, convenient for operator independent
operation at end of machine.
Type | Unit | SYK1425 |
Design speed | Pcs/min | 80 |
Working speed | Pcs/min | 40-60 |
Max paper coverage | mm | 1400*2500 |
Effective printing area | mm | 1400*2500 |
Min finish size | mm | 350*700 |
cardboard thickness | mm | 2.5-12 |
Wall thickness | mm | 40mm |
Print precision | mm | ≤±0.5 |
Slotting precision | mm | ≤±1.5 |
Company Information
Dongguang Ruichang Carton machinery manufacture Co.,ltd established in 1996. We are located in DongGuang County which is famous for packing hometown with convenient transportation to TianJin sea port. We produce many kinds of carton box printing and slotting die cutting machines. Our machine comply with international quality standards and are greatly accepted by customer from domestic and aboard market.
We have over 50 employees, 2 engineers for technical upgrade,1 engineer for machine design ,70% of them worked for RuiChang Machine over 10 years.
Whatsapp:+ 0086 15369817513
FAQ
1.Are you manufacturer ?
Yes, we are a manufacturer with 20 year manufacturing experience and we have our own export company.
License and certificates
2.Do you have experience in packing for shipment?
Yes, we will wrap the machine with plastic flims, packed it with steel shelf and wooden plate then put it into the containers.
3.Who will install the machine when machines arrived in our factory?
We will let the professional installer to your factory and teaching the operater how to use and maintain it. It's free within 7 days. Only to pay for the return tickets and visa expense.
4. Could you provide local service?
Of course, we can provide local service to ensure the medicine could be repaired as soon as possible.
