5 км 15dBi коэффициент усиления антенны urwave птп/PTMP QT 5-15 8 ггц MIMO CPE наружная беспроводная точка


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 0.87 $* 0.87 $*
Aug-18-2025 0.90 $* 0.81 $*
Jul-18-2025 0.29 $* 0.15 $*
Jun-18-2025 0.9 $* 0.94 $*
May-18-2025 0.37 $* 0.93 $*
Apr-18-2025 0.82 $* 0.92 $*
Mar-18-2025 0.98 $* 0.40 $*
Feb-18-2025 0.80 $* 0.96 $*
Jan-18-2025 0.15 $* 0.73 $*

Характеристики



Products Description


URwave QT 5-15 5GHZ MIMO CPE
The URwave QT 5-15 is a versatile, very efficient, and stable 5 GHz CPE. This product is equipped with an extreme output power (up to 29 dBm) 802.11n MIMO radio wrapped securely inside a robust, well designed and a small form factor enclosure. The robust hardware is coupled with a 15 dBi directional panel antenna; ideal for short to medium range applications.
Smart dynamic polling based protocol (iPoll 2) ensures reliable communication even in congested areas with 64 client devices connected to a base-station.
Equipped with the dual firmware image feature, remote software upgrades are assured even if a power failure interrupts the process. The device will restart using the prior firmware in the event of an upgrade failure.
The enclosure is made of polycarbonate plastic with UV inhibitors to provide years of outdoor exposure in direct sunlight without cracking. Tested to meet vibration, temperature, drop, salt, fog, and electrical surge standards to ensure a high level of reliability and backed by a two-year warranty. It is equipped with a grounding lug and a grounded 24-volt PoE to allow a professional installation, resistant to electrical surges




Specification


Radio specifications
Wireless technology
IEEE 802.11 a/n, iPoll(proprietary) , 2x2 MIMO
Operating mode
Bridge, router iPv4, router IPv6
Radio frequency band
5.150 - 5.850 GHz (FCC 5.150 - 5.250 and 5.725 - 5.850 GHz)
Channel size
Configurable 5,10,20, 40 MHz
Max transmit power
29 dBm (country dependent )
Receive sensitivity
Varying between -97 and -75 dBm depending on modulation
Modulation schemes
802.11 a/n: OFDM (64-QAM, 16-QAM, QPSK, BPSK)
Data rates
802.11 n: 300, 270, 240, 180, 120, 90, 60, 30 Mbps
802.11 a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
Error correction
FEC, Selective ARQ
Duplexing scheme
Time division duplex
Antenna
Type
Integrated directional panel antenna
Gain
15 dBi
Elevation beamwidth
H pol: 35deg, V pol: 35deg, Elevation: 35deg
Data Interface
Physical interface
10/100 Base-T
Protocol
Ethernet IEEE 802.3
Connector type
RJ45
Surge protection
Built-in (IEC 61000-4-2 (ESD) and IEC 61000-4-5 (SURGE))
Link performance
Real data throughput
170 Mbps aggregate (90 Mbps full-duplex)
Max packets per second
80,000
Packet latency
2 ms (64 bytes packet)
Recommended link distance
3~5Km
Security
Wireless security
WPA/WPA2 personal, WPA/WPA2 enterprise, WACL, user isolation
Physical
Dimensions
140mm (5.51 ‘’),90mm (3.54 ‘’), 35 mm (1.38 ‘’)
Weight
122g (4.3oz) (mount included)
Power supply
12 - 24 VDC passive PoE (24 V passive PoE adapter is included in the package)
Power source
100 – 240 VAC
Power consumption
4.5W
Environmental
Operating temperature
-40°C (-40 F) ~ +65°C (+149 F)
Humidity
0 ~ 90 % (non-condensing)
Management
System configuration
Web UI, WNMS
System monitoring
SNMP v1/2c/3 server, Syslogs, system alerts via e-mail and SNMP trap
Regulatory
Certification
FCC/IC/CE
Ingress protection
IP-65
Safety
RoHS compliant
