50T передвижной кран подъемный

Item

Unit

Value

Remarks

Working

 performance

Max.    rated lifting capacity

kg

55000

Max.    load moment of basic boom

kN.m

2009

Max.    load moment of main boom(fully extended)

kN.m

1050

Max.    load moment of basic boom

m

12.6

Max.    lifting height of main boom

m

43.6

These    parameters do not include deflection of main boom and jib

Max.    lifting height of jib

m

58

Working

 speeds

Max.    hoist rope speed(Main winch)

m/min

120

Max.    hoist rope speed(Auxiliary winch)

m/min

120

Boom    demrricking up time

s

50

Boom    demrricking up time

s

95

Slewing  speed

r/min

0-2

Driving    parameters

Max.    height above sea level

m

2000

Max.    driving  speed

km/h

76

Max.

gradeability

%

40

Min. turning diameter

m

≤24

Min.  ground clearance

mm

260

Oil    consumption per hundred kilometers

L

43

Mass

Deadweight    in driving condition

kg

42000

Complete

 vehicle kerb mass

kg

41870

Front    axle load

kg

16000

Rear    axle load

kg

26000

Dimensions

Overall  dimensions(L×W×H)

mm

13700×2800×3800

Outrigger

 spread(L)

m

5.92

Outrigger

 spread(W)

m

Fully    extended:7.1,intermediately extended:4.8
