3-6 тонн сверхмощный буксируемый экскаватор мини экскаватор-погрузчик на
- Категория: Погрузчики >>>
- Поставщик: Shandong,Ucarry,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 22015.10 $* | 23116.40 $* |
| Aug-19-2025 | 21830.11 $* | 22922.98 $* |
| Jul-19-2025 | 18315.4 $* | 19231.81 $* |
| Jun-19-2025 | 21460.46 $* | 22533.55 $* |
| May-19-2025 | 18685.85 $* | 19619.88 $* |
| Apr-19-2025 | 21090.66 $* | 22145.75 $* |
| Mar-19-2025 | 20905.26 $* | 21950.23 $* |
| Feb-19-2025 | 20720.44 $* | 21756.17 $* |
| Jan-19-2025 | 20535.67 $* | 21562.92 $* |
Характеристики
Sale Large And Mini Front End Loader Tractor 2.5Ton Multifunction Wheel Backhoe Loader
Product Description
Product name | Backhoe Loader | ||||
The Main Performance Parameter of Backhoe Loader UR388 | |||||
Overall Operating Weight | 8200KG | Final Reducer | Single Stage Final Reducer | ||
Transport Dimension | Rated Loader of Axle | 4/18.5t | |||
L*W*H mm | 6150×2250×3763 | Transmission System | |||
Wheel base | 2200mm | Torque Converter | |||
Min. Ground Clearance | 300mm | Model | YJ280 | ||
Bucket Capacity | 1.0m3 | Type | Single-stage Three Elements | ||
Breakout Force | 38KN | Max. Efficiency | 84.4% | ||
Loading Lifting Capacity | 2500KG | Inlet Pressure | 0.4Mpa—0.55 Mpa | ||
Bucket Dumping Height | 2742mm | Outlet Pressure | 1.2Mpa—1.5 Mpa | ||
Bucket Dumping Distance | 1062mm | Cooling Method | Oil-cooling Pressure Circulation | ||
Digging Depth | 52mm | Gearbox | |||
Backhoe Capacity | 0.3 m3 | Type | Fixed Shaft Power Transmission | ||
Max. Digging Depth | 4082mm | Oil Pressure of Clutch | 1373Kpa—1569 Kpa | ||
Swing Angle of Excavator Grab | 190o | Gears | Two Gears Ahead, Two Gears Astern | ||
Max. Pulling Force | 39KN | Max.Speed | 22Km/h | ||
Engine | Tyre | ||||
Model | YC4A105Z-T20 | Model | 14-17.5/19.5L-24 | ||
Type | turbocharging four-stroke | Pressure of Front wheel | 0.22 Mpa | ||
Cylinder-Inside Diameter*Stroke | 4—105 | Pressure of Back Wheel | 0.22 Mpa | ||
Rated Power | 75KW/100HP | Brake System | |||
Rated Speed | 2400r/min | Service Brake | Air Over Oil Caliper Brake | ||
Min. Fuel Consumption | 235g/kw.h | External Type | |||
Max.Torque | 310NM | Self-regulation | |||
Displacement | 4.3L | Self-balance | |||
Steering System | Emergency Brake | Operation Power Implementing brake | |||
Model of Steering Device | BZZ5-250 | Manual Operation Power Terminating Brake | |||
Steering Angle | ±36 o | Hydraulic System | |||
Min. turning radius | 6581mm | Digging Power of Excavator Grab | 46.5KN | ||
Pressure of the system | 12Mpa | Digging Power of Dipper | 31KN | ||
Axle | Bucket Lifting Time | 5.4S | |||
Manufacturer | Feicheng Axle Factory | Bucket Lowering Time | 3.1S | ||
Main Transmission Type | Double Reduction | Bucket Discharge Time | 2.0S | ||
Note:The parameters are subject to change without notice | |||||
1.The machine is of compact structure and logical layout.
2.Good appearance and design of components embody humanization adequately.
3.The performance has achieved advanced level in China.
4.The imported components are used as the transmission system and the hydraulic system uses domestic famous brand.
5.The panoramic cabin is of broad vision.
6.The professional designed operation system as well as reasonable layout realizes comfortable, convenient and labor-saving operation.
7.The steering axle with big swing angle and steering angle makes the machine better passing-ability.
8.The driving axle with differential lock and wet disc brake significantly improve the traction and safety performance.
9.The service brake and parking brake adopts maintenance-free, self-adjusting wet disc brake.
10.The cover with open-back design improves maintainability.
11.It can be fixed with many accessories according to requirements.
Company Information
Packaging & Shipping
FAQ
Q: Do you have any advantage ?
A: We are professional wheel loader/ excavator/ backhoe loader/ forklift loader/mucking loader/telescopic loader/tractor manufacturer/exporter with many years experiences. Competitive price, high quality, meet different customers' needs, good after sale service... are our advantages.
Q: How long is your loader warranty time? How to do after sale service?
A: 1 year.We can do after-sales service by all possible means. If necessary, engineers will visit customers and do the after sale service.
Q: Do you have the certification of loaders?
A: Yes, all of loaders are approved by CE, ISO9001, SGS certification, except these other certifications required by customer is agreed.
Q: What’s the payment terms of your company?
A: We always do it by T/T 30% deposit, the other 70% before delivery. L/C payment escrow west union etc. are also available.
Q: How about the delivery time?
A: Usually the delivery time will be within two weeks.For some special products,the delivery time will be 20-30 days.
