Мини-ПК 10 поколения Nuc i7 10750H i9 9880H 6 Core i5 2 * DDR4 M.2 NVME AC WiFi игровой настольный компьютер 4K HTPC DP HD Все в
- Категория: Desktops >>>
- Поставщик: Dongguan,Mini,Tree,Computer,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.98 $* | 0.48 $* |
| Aug-17-2025 | 0.7 $* | 0.72 $* |
| Jul-17-2025 | 0.29 $* | 0.94 $* |
| Jun-17-2025 | 0.51 $* | 0.67 $* |
| May-17-2025 | 0.24 $* | 0.19 $* |
| Apr-17-2025 | 0.65 $* | 0.89 $* |
| Mar-17-2025 | 0.70 $* | 0.49 $* |
| Feb-17-2025 | 0.44 $* | 0.33 $* |
| Jan-17-2025 | 0.59 $* | 0.4 $* |
Характеристики
10th Gen Nuc i7 10750H i9 9880H 6 Core i5 Mini PC 2*DDR4 2*M.2 NVME AC WiFi Gaming Desktop Computer 4K HTPC DP HD all in one pc
Buy with confidence ! 3 Years long warranty for Mini Tree pc!
Product Description
Processor parameter for referance only:
1. 9th Gen 14nm CPU Coffee Lake Intel Core i7 9850H 6 cores 12 threads 2.6GHz up to 4.6GHz 12MB cache TDP 45W UHD Graphics 630.
2. 9th Gen 14nm CPU Coffee Lake Intel Core i9 9880H 8 cores 16 threads 2.3GHz up to 4.8GHz 16MB cache TDP 45W UHD Graphics 630.
3. 10th Gen 14nm CPU Comet Lake Intel Core i7 10750H 6 cores 12 threads 2.6GHz up to 5.0GHz 12MB cache TDP 45W UHD Graphics 630.
Feature
RAM :DDR4 2400MHz Two SO-DIMM solt, Support up to 64GB
Storage: 1). + std-2.5”9.5mm HDD,UP to 3TB
2). NGFF(M.2) 22*80(Key M) Slot ,UP to 2TB (Only Nvme PCIe3.0x4 )
3). NGFF(M.2) 22*80(Key M) Slot,UP to2TB (Nvme or SATA)
Wireless :a. 2.4G or 5G Wifi B/G/N/ac
b.Bluetooth(Depend on wireless module ) ( PCIe x1: M.2 22x30 (key E) slot)
I/O Port : 4* USB 3.0 + 2* USB2.0+1X Type-C (USB3.1),1X Headphone-out/ MIC-in phone jack,1X DP1.2 out (support 4k@60Hz),1X HDMI2.0 out (support 4K@60Hz) ,1X DC power,2X RJ45
Operating System : Support Windows 8/10, Linux, Ubuntu OS, and more
Support PXE, AWAL, RTC, Auto power on.
What is in the package
1x Mini PC
1x AC adapter ( we ship correct power plug base on buyer's address )
1x Power cord
1x WiFi module and antennas ("NO SSD NO RAM" bundle package without WiFi module and antennas )
1x SATA Power cable & data cable
1 x User manaul & warranty card
About the taxs
1. Normally we'll write a suitable lower deslare value(like $80-$100) of item to reduce the tariff for customers, because buyer bare responsible for paying tax involved, such as import tax, VAT, etc.
2. If you have special requirement of the value, please leave a message to us when you make order.
3. Due to the tax problem, buyer refuse to receive the goods, buyer need to responsible for the freight back and forth. Thank you for you cooperation.
About warranty
1. Mini Tree pc have 3 years warranty service is completely reliable and professional technical team. Motherboard warranty time 3 years, ram, hard drive, accessories etc warranty time 1 year.
2. Within warranty time, if mini PC appear non-human damages and quality problems, buyer return Mini PC or Mini PC components, we free repair/exchange Mini PC or Mini PC components ( include RAMs, Hard Drive, Motherboard and other accessories ). Within 1 month, seller bear all the shipping cost for return(maximum 15USD)and resend;Over 1 month to 1 year, buyer self bear the shipping cost for return and seller bear shipping cost for resend; Over 1 year to 3 years, buyer bear all shipping cost return and resend.
3. Within 15 days, we accept refund or exchange goods (buyer bear all the shipping cost, if non-human damages and quality problem, we bear all shipping cost.
4. All time calculate from the day buyer receive goods.
Basic Information: | |
CPU | Intel Core i9-9880H / Intel Core i9-8950HK |
CPU install Method | BGA1440 |
TDP | 45W |
Level 2 Cache | Depend on CPU |
Motherboard | 136 x 126mm customized size |
Code Name | Intel Coffee Lake |
Chipset | Intel 300 series PCH |
Memory | 2 x SO-DIMM Slot, up to 64GB DDR4 Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz ECC Memory Support: YES |
OS | Windows 10 |
Audio | Azalia Codec support 2.1 channel output High Definition Audio Controller |
Network | 1)10/100/1000Mbps Ethernet 2) Intel® Ethernet Connection I219-V 3) Intel® Ethernet Connection I211-AT |
Video | Intel® UHD Graphics 630 |
Input/output port | |
Switch | 1 x Power On/Off Switch |
Power | 1 x 19V DC In |
LED | 1 x LED |
USB | 4 x USB3.0, 2X USB2.0 |
Type-C | 1 x Type-C USB3.1 |
Display | 1 x DP1.2 out(support 4k@60Hz), 1 x HDMI2.0 out(support 4K@60Hz) |
LAN | 2 x RJ45 Intel Giga LAN |
Audio | 1 x Audio(MIC&SPK) |
Others | 1 x Kensington Lock hole |
Storage |
|
MSATA | 1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s 1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(NVME/SATA), support 6Gb/s |
SATA | 1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s |
Wi-Fi |
|
Module | 1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth) |
Antenna | 2 x inner RF cables and 2 x external antennas |
Power and Working Environment | |
Input | DC100-240V AC/50-60Hz |
Output | DC +12V~+19V, recommend 19V 90W |
Operating Temperature | 0/70 Centigrade |
Storage Temperature | -20/+80 Centigrade |
Relative Humidity | 0%~90% (non-condensing) |
Product Dimension & Details | |
Size | 134*144*64mm |
Weight | Net 1.05kg, Gross 3.0kg |
Shell | Brushed Black color aluminum alloy |
Cooling Mode | Cooling Fan |
Functions | 1) Intel® Optane™ Memory Supported: Yes 2) Intel® Virtualization Technology (VT-x): Yes 3) Wake on Lan : Yes 4) Wake on AC : Yes 5) PXE Boot: Yes. |
Package Content |
|
Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1xVESA mount |
Optional | Wi-Fi antennas, 1xHDMI cable, 1xUser Manual |
Company Information
FAQ
Can you provide OEM/ODM service? How much do I need to pay for your OEM service?
Yes we can. The charges for OEM service depends on the different level of customize. the process of customization is following:
1) provide your specific requirement.
2) our design engineer draw the design draft.
3) you confirm the design draft.
4) we start produce it.
Can you print my logo on the mini computer ?
Re: Yes, it is support . And we could print your logo on the pc for free !
Pls contact me for logo printing ;)
What is the Minimum Order Quantity (MOQ)?
Re: We can sell one piece sample for your test.
What is the lead time of your products?
Re: Sample order within 3-7 business days . Bulk order within 3~15 business days ( depends on order qty) ,we will test the model to insure the quality before shipping.
How will you deliver my goods to me?
Re: We ship by air generally. In the meantime, we cooperate with international expresses such as DHL, UPS, FedEx, and TNT to enable our customers to get their goods rapidly.
What's the warranty?
Re: 3 year warranty ! After expired warranty and sent back to our company, we will still try our best to repair for you without repair cost (except change new accessories).
