Автоматический энергосберегающий пластиковый колпачок с регулируемым насосом/машина для изготовления пластиковой посуды
- Категория: Injection Molding Machine >>>
- Поставщик: Zhangjiagang,Sky,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 21420.86 $* | 22491.27 $* |
| Aug-19-2025 | 21240.8 $* | 22302.33 $* |
| Jul-19-2025 | 17820.78 $* | 18711.31 $* |
| Jun-19-2025 | 20880.25 $* | 21924.75 $* |
| May-19-2025 | 18180.0 $* | 19089.76 $* |
| Apr-19-2025 | 20520.13 $* | 21546.59 $* |
| Mar-19-2025 | 20340.92 $* | 21357.74 $* |
| Feb-19-2025 | 20160.36 $* | 21168.64 $* |
| Jan-19-2025 | 19980.98 $* | 20979.53 $* |
Характеристики
Production Application
Product Description
Our injection Molding Machine uses proportional pressure and flow control, the pressure and the speed can be adjusted, stable movement curve and gentle shock,
the computer is imported from Industry family.The LCD displaying screen with high clarity has Chinese and English language to
use.Close-loop PID temperature control with the advantage of high precision.The operating table of the injection moulding machine
have two safety, one is machine safety, another is electrical safety, that ensures the operators's safety.
High Efficiency Energy Saving Injection Molding Machine:
1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container
the computer is imported from Industry family.The LCD displaying screen with high clarity has Chinese and English language to
use.Close-loop PID temperature control with the advantage of high precision.The operating table of the injection moulding machine
have two safety, one is machine safety, another is electrical safety, that ensures the operators's safety.
High Efficiency Energy Saving Injection Molding Machine:
1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container
Clamping Unit
5-point twin toggle clamping system by modular optimization software designing.Strong clamping with rapid and stable, to meet the strict clamping condition.
Mold height adjustment by hydraulic driven gear system with rapid and stable.
Automatic mold height adjustment as per the setting clamping force(optional).
Injection Unit
BaIanced double injection cylinder technology makes screw to have evenly distributed force during fast injection,
Five_star Hydraulic motor with big torque.
Ensure the excellent plastic molding condition.
Research and develop different screws according to different injection condition, suitable for the progressive demand and greatly improve the injection quality.
Control Unit
Imported computer special for Injection Molding Machine with multiple functions and precise control processing.
World famous electrical components and high quality circuit hardware with stable and reliable running.
5-point twin toggle clamping system by modular optimization software designing.Strong clamping with rapid and stable, to meet the strict clamping condition.
Mold height adjustment by hydraulic driven gear system with rapid and stable.
Automatic mold height adjustment as per the setting clamping force(optional).
Injection Unit
BaIanced double injection cylinder technology makes screw to have evenly distributed force during fast injection,
Five_star Hydraulic motor with big torque.
Ensure the excellent plastic molding condition.
Research and develop different screws according to different injection condition, suitable for the progressive demand and greatly improve the injection quality.
Control Unit
Imported computer special for Injection Molding Machine with multiple functions and precise control processing.
World famous electrical components and high quality circuit hardware with stable and reliable running.
Product Paramenters
Model | BST-1320A | BST-2600A | |
Injection Unit | A | B | |
Screw Diameter(mm) | 38 | 40 | |
Shot Size(theoretical)(cm³) | 210 | 228 | |
Shot Weight（g） | 188 | 205 | |
Injection Pressure（Mpa） | 176 | 160 | |
Injection Rate（g/s） | 95 | 100 | |
Screw L/D Ratio（L/D） | 22.8 | 21.7 | |
Screw Speed（rpm） | 0-190 | ||
Nozzle Diameter（Srmm） | 10 | ||
Clamping | |||
Clamp Tonnage(KN) | 1320 | ||
Toggle Stroke(mm) | 350 | ||
Mold Thickness(mm) | 150-420 | ||
Space Between Tie-bars(mm) | 554*554 | ||
Ejector Stroke(mm) | 410*375 | ||
Ejector Tonnage(KN) | 50 | ||
Ejector Number(pcs) | 5 | ||
Hole Diameter(mm) | 100 | ||
Others | |||
Heat Power(KW) | 8.2 | ||
Max Pump Pressure(MPa) | 16 | ||
Pump Motor Power()KW | 13 | ||
Valve Size(mm) | 10 | ||
Machine Dimension(m) | 4.5*1.6*1.7 | ||
Machine Weight(T) | 3.9 | ||
Oil Tank Capacity(L) | 200 | ||
Auxiliary Equipment
Hopper Dryer
Direct-drive hopper dryers are the most efficient and rapidly economical and applied machine to dry the plastics material, it can
dry the wet material for package ,transportation of recycle, all the models can choose to add the 24-hour timer, a week timer or microcomputer control (containing P.I.D) temperature automatic controller,99-hour time, fault indication.
dry the wet material for package ,transportation of recycle, all the models can choose to add the 24-hour timer, a week timer or microcomputer control (containing P.I.D) temperature automatic controller,99-hour time, fault indication.
Auto Loader
Auto loaders are designed and developed on the basis of original separate-vacuum Hopper Loaders. They feature more functions, easy to operate, and convenient to install. This model, equipped with a high pressure blower and more hoppers, is
applicable to more dehumidifying and drying machines (dehumidifying dryer "CDD" or one gravimetric blenders "CGB" to process
plastic materials. Besides that , it can also realize the one-to-more way of conveying materials to different moulding machines or
hoppers to greatly lower the cost.
applicable to more dehumidifying and drying machines (dehumidifying dryer "CDD" or one gravimetric blenders "CGB" to process
plastic materials. Besides that , it can also realize the one-to-more way of conveying materials to different moulding machines or
hoppers to greatly lower the cost.
Crusher
This series of hammer crusher is applicable for crushing brittle minerals, such as coal, salt, plaster, alum, brick, tile and limestone with compression strength no more than 100mpa and humidity no more than 15%. The hammer crusher crushes by the collisions between high-speed hammer and materials. The PC hammer crusher is developed for both dry and wet crushing of brittle, medium-hard materials for the mining, cement, coal, metallurgic, construction material, road building and petroleum & chemical industries.
Recommend Products
Company Introduction
After Sales Service
1.Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered.We will arrange
seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated
producing capacity of the line.Time for installation and debug is 15-25 days.
2.Training
Our company offer technology training to customer.The content of training is structure and maintenance of equipment, control and
operation of equipment.Training is in the workshop of customer.Seasoned technician will guide and establish training outline.After
training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different
failures.
3.Quality guarantee
We promise that our goods are all new and not used.They're made of suitable material, adopt new design.The quality, specification
and function all meet the demand of contract.We promise that the products of this line could storage for one year without adding
any aseptic.
4.After sales
1,After checking, we offer 12 months as quality guarantee, free offer wearing parts and offer other parts at the lowest price.In
quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some
failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not solve, we will arrange
technician to your factory solving the problems.The cost of technician arrangement you could see the cost treatment method of
technician.
2,After quality guarantee, we offer technology support and after sales service.Offer wearing parts and other spare parts at
favorable price;After quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's
demand, debug some failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not
solve, we will arrange technician to your factory solving the problems.The cost of technician arrangement you could see the cost
treatment method of technician.
After equipment reached the workshop of customer, place the equipment according to plane layout we offered.We will arrange
seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated
producing capacity of the line.Time for installation and debug is 15-25 days.
2.Training
Our company offer technology training to customer.The content of training is structure and maintenance of equipment, control and
operation of equipment.Training is in the workshop of customer.Seasoned technician will guide and establish training outline.After
training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different
failures.
3.Quality guarantee
We promise that our goods are all new and not used.They're made of suitable material, adopt new design.The quality, specification
and function all meet the demand of contract.We promise that the products of this line could storage for one year without adding
any aseptic.
4.After sales
1,After checking, we offer 12 months as quality guarantee, free offer wearing parts and offer other parts at the lowest price.In
quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's demand, debug some
failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not solve, we will arrange
technician to your factory solving the problems.The cost of technician arrangement you could see the cost treatment method of
technician.
2,After quality guarantee, we offer technology support and after sales service.Offer wearing parts and other spare parts at
favorable price;After quality guarantee, the technician of buyers should operate and maintain the equipment according to seller's
demand, debug some failures.If you could not solve the problems, we will guide you by phone;If the problems are still can not
solve, we will arrange technician to your factory solving the problems.The cost of technician arrangement you could see the cost
treatment method of technician.
FAQ
1. A: Are you factory?How many workers do you have? B: Yes,we are factory. our factory is located in zhangjiagang near from
shanghai. We have about 50 workers in our factory. 2. A: What about after sale service? B: 12months of electrical part and
18months of mechanical part after machine installed and running normally. 3. A: What about installation? B: Our engineer can be
sent to your country. but customer should pay the air tickets and 100usd as salary per person per day. besides, customer should
arrange the accommodation for them during the trip. 4. A: What do we do if we encounter problem about the machine ? B: Show us the
picture or video of the problem. If the problem is from small machine, we will send you solution by video. If the problem is from
large machine, our engineer will go to your factory (customer will pay the fee during the trip). 5. A: How can you control the
quality and delivery? B: All our machines will be tested before packaging. wooden packaing is strong and safety for long delivery
.
shanghai. We have about 50 workers in our factory. 2. A: What about after sale service? B: 12months of electrical part and
18months of mechanical part after machine installed and running normally. 3. A: What about installation? B: Our engineer can be
sent to your country. but customer should pay the air tickets and 100usd as salary per person per day. besides, customer should
arrange the accommodation for them during the trip. 4. A: What do we do if we encounter problem about the machine ? B: Show us the
picture or video of the problem. If the problem is from small machine, we will send you solution by video. If the problem is from
large machine, our engineer will go to your factory (customer will pay the fee during the trip). 5. A: How can you control the
quality and delivery? B: All our machines will be tested before packaging. wooden packaing is strong and safety for long delivery
.
