Многофункциональная упаковочная машина для пакетов 40-50 кг взвешивания зерновых семян закусок
- Категория: Табака обрабатывающее оборудование >>>
- Поставщик: Zhengzhou,Huayu,Briquette,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 7378.71 $* | 7747.59 $* |
| Aug-18-2025 | 7316.17 $* | 7682.87 $* |
| Jul-18-2025 | 6138.86 $* | 6445.0 $* |
| Jun-18-2025 | 7192.73 $* | 7552.21 $* |
| May-18-2025 | 6262.61 $* | 6575.42 $* |
| Apr-18-2025 | 7068.5 $* | 7421.8 $* |
| Mar-18-2025 | 7006.71 $* | 7356.11 $* |
| Feb-18-2025 | 6944.10 $* | 7291.29 $* |
| Jan-18-2025 | 6882.15 $* | 7226.2 $* |
Характеристики
Product Description
Automatic Weighing Vertical Packaging Machine Powder Pellets Packaging Machine Price Multi-function+Packaging+Machines
It is suitable for the packaging of chemical fertilizer raw materials and granular objects such as urea, BB fertilizer, diamine, blended fertilizer and feed. Manual bagging, automatic filling, automatic weighing, automatic bag placement, manual auxiliary sealing. The instruments and meters are imported, the material contact part is stainless steel, accurate measurement and stable performance.
Introducction of the packing machinie structure
1.Feeding device: it adopts intelligent material feeding structure, via computer transducer or reducing motor control module, to realize the fast and slow speed feeding. And, according to different materials, you could adjust the feeding speed by adjusting the transducer ( no interference ). The maximum adjustment range is 100%. Meanwhile, if also adjust the parameter setting, it could achieve the best optimal proportion of fast and slow speed feeding and ensure to increase the packing speed and keep good accuracy.2.Bag clamping device:It adopts pneumatic clamping device, consist of annular bag clamping bucket, clamping system, executive device and bag placing signal. And the annular bag clamping bucket installed with air return way. If there’s dust during filling into bag, in the outlet, it could equip trumpet shaped air suction hood and connect with the factory dust-collect system to improve the workers’ working environment.
3.Weighing system:It adopts Sensors Systems, weighing load cells which with high accuracy, durability, steady working,
and impact resistance. They are matched with sole drive connection structure to fix them with the bag clamping device and weighing system.
4.Weighing control unit: It includes weighing control cabin, electromagnetic valve, proximity switch, weighing terminal, programmed weighing controller, isolation transformer, power supply switch and relative components. It’s the brain of the
packing machine working.
Specification
Model | DCS-50 |
Total Power | 4kw |
Sewing power | 0.37kw |
Host power | 0.55kw |
Gas power | 3kw |
Inner material | 304 stainless steel |
Accuracy | ≤2‰ |
Speed | 5-8 bales/min |
Sewing height | adjustable |
Main engine size | 1000*750*2000mm |
Outline | 3300*1000*2800mm |
Note:
we also have other models, if any need, just contact me:email: jessie@cnhypa.com
whatsapp: +86 18236967857
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
Zhengzhou Huayu Briquette Equipment Co., Ltd is a manufacturer of briquette machine with well-equipped testing facilities and strong technical force.With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in power plants and other industries.Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
