Недорогие Заводские солнечные гелевые батареи 200 ач 12 В свинцово-кислотная батарея 100 Ач Европейская
- Категория: Other Batteries >>>
- Поставщик: Guangzhou,Felicity,Solar,Technology,Company,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 95.87 $* | 97.93 $* |
| Jul-16-2025 | 77.18 $* | 79.49 $* |
| Jun-16-2025 | 94.30 $* | 96.49 $* |
| May-16-2025 | 93.87 $* | 95.18 $* |
| Apr-16-2025 | 74.59 $* | 75.31 $* |
| Mar-16-2025 | 92.2 $* | 94.50 $* |
| Feb-16-2025 | 91.39 $* | 93.32 $* |
| Jan-16-2025 | 90.92 $* | 92.7 $* |
Характеристики
Product Introduction
Details Images
>>Advantages
1.Seale and maintenance free operation.
2.Non-spillable construction design.
3.ABS containers and covers(UL94HB,UL94V-0)optional.
4.Safety value installation for explosion proof.
5.High quality and high realiability.
6.Exceptional deep discharge recovery performance.
7.Low self discharge characteristic.
8.Flexibility design for multiple install positions.
Product Application
>>Apllication
1.UPS System 2.Telecommunication System
3.Power Station System 4.Railway System
5.Emergency Lighting System 6.Automatic Control System
7.Alarm Systems for Fire Protection Security 8. Solar, Wind Power Systems
9.Portable Instruments 10 .Medical Equipment
11.Marine Equipment 12.Electric Instruments
Product Parameters
Model | FL-G-100AH12V | FL-G-150AH12V | FL-G-200AH12V | |||||||
Rated Capacity(10hour Rate) | 100Ah | 150Ah | 200Ah | |||||||
Dimensions | 216*330*171mm | 241*483.5*170mm | 219*552*240mm | |||||||
Weight | 28.5 kg | 39 kg | 57.5 kg | |||||||
Characteristics capacity 25℃（77.℉） | 10 hour rate(10.0A) | 100AH | 10 hour rate(10.0A) | 150AH | 10 hour rate(10.0A) | 200AH | ||||
5 Hour rate(16.0A) | 80AH | 5 Hour rate(16.0A) | 120AH | 5 Hour rate(16.0A) | 160AH | |||||
1 hour rate(60A) | 60AH | 1 hour rate(60A) | 90AH | 1 hour rate(60A) | 120AH | |||||
1.5 hour discharge to 10.5V | 40AH | 1.5 hour discharge to 10.5V | 60AH | 1.5 hour discharge to 10.5V | 80AH | |||||
Charge (Constant voltage) | Initial charging current less than 30A Voltage 14.4-14.8V (14-16 hours) | Cycle | Initial charging current less than 45A Voltage 14.4-14.8V(14-16 hours) | Cycle | Initial charging current less than 60A Voltage 14.4-14.8V (14-16 hours) | Cycle | ||||
Float | 13.5-13.8V | |||||||||
Capacity affected by temperature(10 hour rate) | 40℃104℉ | 102% | ||||||||
25℃77℉ | 100% | |||||||||
0℃32℉ | 85% | |||||||||
-15℃5℉ | 65% | |||||||||
Self-Discharge at 25℃77℉ | Capacity after 3 month storage | 91% | ||||||||
Capacity after 6 month storage | 82% | |||||||||
Capacity after 12 month storage | 64% | |||||||||
Terminal | T10 | T11 | T11 | |||||||
Europe Model | FL-GE-150AH12V | ||||
Cells Per Unit | 6 | ||||
Voltage Per Unit | 12 | ||||
Capacity | 150Ah@10hr-rate to 1.80V per cell @25 C | ||||
Weight | Approx.45.0Kg ( ± %) | ||||
Max. Discharge Current | 1500 A (5 sec) | ||||
Internal Resistance | Approx. 4 mΩ | ||||
Operating Temperature Range | Discharge: -20 ~60℃ Charge: 0~50 ℃ Storage: -20~60 ℃ | ||||
Normal Operating Temperature Range | 25 C±5 C | ||||
Float charging Voltage | 13.6 to 13.8 VDC/unit Average at 25 C | ||||
Recommended Maximum Charging Current Limit | 45 A | ||||
Equalization and Cycle Service | 14.6 to 14.8 VDC/unit Average at 25 C | ||||
Self Discharge | RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for more than 6 months at 25 C. Self-discharge ratio less than 3% per month at 25 C. Please charge batteries before using. | ||||
Terminal | Terminal F9 | ||||
Container Material | A.B.S. UL94-HB, UL94-V0 Optional | ||||
Dimension | 555*110*228mm | ||||
Dimension
