D1004 4 канала класса d 1u Профессиональный цифровой аудио звук 3000w усилитель мощности с

Описание и отзывы

Трекер стоимости

Характеристики

1U  Class D digital power amplifier
Applications
Mobile performance / portable sound reinforcement

KTV/Bar/Concert Hall

Gymnasium / Arena

Features
 1.1U height standard chassis, compact, lightweight and compact

 2.Class D power amplifier module with fixed switching frequency

 3.Soft Switch LLC Resonant Switching Power Supply Module

 4.Active Power Factor Correction (PFC) for stable operation over full voltage (90-264V)

 5.Efficient speaker back EMF absorption system

 6.Unique peak clipping limiter and ripple elimination network

 7.Temperature-controlled variable speed fan, airflow from front to back

 8.Backplane connection mode selection (stereo/parallel/bridge)

 9.The back panel is equipped with input sensitivity selection switching (0.775v/1v/32dB)

 10.Complete circuit protection, including: soft start, DC, sub audio, high frequency, overheat, short circuit, power on/off mute

 12.Low frequency and powerful, very low dive depth, medium and high frequency transparent, clear and pleasant

 13.Integrated design of power amplifier module and power module, more than 85% of the devices use automation to ensure product consistency

Product Specification:



2 channel

Model		D1002	D1502	D1802	D2402	D2802
Output power(RMS) Stereo	8Ω	2×1000W	2×1500W	2×1800W	2×2400W	2×2800W
	4Ω	2×1600W	2×2400W	2×3000W	2×3800W	2×4500W
	2Ω	2×1900W	2×2900W	2×3800W	2×5000W	2×5500W
Output power(RMS) Bridge	8Ω	3200W	4800W	6000W	7600W	9000W
	4Ω	3800W	5800W	7600W	10000W	N/A



4 channel

Model		D6504	D8004	D1004	D1504	D1804
Output power(RMS) Stereo	8Ω	4×650W	4×800W	4×1000W	4×1500W	4×1800W
	4Ω	4×1050W	4×1300W	4×1600W	4×2300W	4×2800W
Output power(RMS) Bridge	8Ω	2×2100W	2×2600W	2×3200W	2×4600W	2×5600W
