Новый оригинальный шлюз Yeastar TG серии VoIP GSM / WCDMA 4G LTE

Новый оригинальный шлюз Yeastar TG серии VoIP GSM / WCDMA 4G LTE

Категория: АТС >>>
Поставщик: Shenzhen,Semi,Matrix,Technology,Limited,Company

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.19 $*	0.63 $*
Aug-16-2025	0.26 $*	0.27 $*
Jul-16-2025	0.96 $*	0.54 $*
Jun-16-2025	0.15 $*	0.31 $*
May-16-2025	0.32 $*	0.10 $*
Apr-16-2025	0.31 $*	0.47 $*
Mar-16-2025	0.56 $*	0.35 $*
Feb-16-2025	0.42 $*	0.10 $*
Jan-16-2025	0.38 $*	0.12 $*

Характеристики

New original Yeastar TG Series

VoIP GSM / WCDMA / 4G LTE Gateway

TG800

Product Description

Yeastar TG Series VoIP GSM Gateways connect GSM or WCDMA or 4G LTE to VoIP networks to provide two-way communication: GSM/3G/4G to VoIP and VoIP to GSM/3G/4G. This allows you to connect most IP-based telephone systems including Yeastar IP Phone Systems, and softswitches to a GSM or 3G WCDMA or 4G LTE; which can provide a sophisticated fallback solution when landlines go down, or be used to increase call traffic capacity by providing additional dial-tone.

GSM Voice Calls
VoLTE for HD Calls
Maximum Cost Reduction
Top Quality and Reliability
Mobile Connectivity for SMB

Skype ID : live:yangguan001

Specifications

Models*	TG100	TG200	TG400	TG800	TG1600
Number of Ports	1	2	4	8	16
GSM Frequency**	850/900/1800/1900 MHz
UMTS Frequency**	850/1900 MHz, 850/2100 MHz, 900/2100 MHz
GSM and 3G and 4G channel Frequency**	Don’t support 4G LTE	FDD-LTE:B1/B3/B5/B7/B8/B20, TDD-LTE:B38/B39/B40/B41,WCDMA:B1/B5/B8, TD-SCDMA:B34/B39, CDMA 2000:BC0,CDMA 1X:BC0, GSM:B3/B8
4G LTE Band**	Don’t support 4G LTE	Depending on the module type. Check the supported band and operators.
Protocol	SIP, IAX2
Antenna Splitter (4 in 1)	–		Support
Transport	UDP, TCP, TLS, SRTP
Voice Codec	G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex
DTMF Mode	RFC2833, SIP Info, In-band
Echo Cancellation	ITU-T G.168 LEC
Calling Type	Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)
Console Port	–			1
Network Protocol	FTP, TFTP, HTTP, SSH
LAN	1 10/100 Mbps Ethernet Interface			2 10/100 Mbps Ethernet Interfaces
NAT Traversal	Static NAT, STUN
Network	DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Operation Range	0°C to 40°C, 32°F to 104°F
Power Supply	DC 12V, 1A	AC 100-240V
Storage Range	-20°C to 65°C, -4°F to 149°F
Dimensions (L × W × H) (mm)	110 x 70 x 24	213 x 160 x 44		340 x 210 x 44	440 x 250 x 44
Humidity	10-90% non-condensing
