Китайский производитель оптовая продажа лента из медного сплава Длина 9-10 мм разъем
- Категория: Клеммы >>>
- Поставщик: Ningbo,Supu,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.58 $* | 0.71 $* |
| Aug-17-2025 | 0.22 $* | 0.87 $* |
| Jul-17-2025 | 0.86 $* | 0.43 $* |
| Jun-17-2025 | 0.21 $* | 0.40 $* |
| May-17-2025 | 0.23 $* | 0.13 $* |
| Apr-17-2025 | 0.69 $* | 0.43 $* |
| Mar-17-2025 | 0.40 $* | 0.96 $* |
| Feb-17-2025 | 0.95 $* | 0.74 $* |
| Jan-17-2025 | 0.58 $* | 0.51 $* |
Характеристики
Product Description
| Model | MC-DRT3.5HXXP-A | |||
| IEC Rated data | ||||
| Wire range | 0.2-1.5mm² | |||
| Solid | 0.2-1.5mm² | |||
| Stranded | 0.2-1.5mm² | |||
| Stranded with ferrules without plastic sleeve | – | |||
| Stranded with ferrules with plastic sleeve | – | |||
| Strip length | 9–10mm | |||
| Overvoltage level | Ⅲ | Ⅲ | II | |
| Pollution level | 3 | 2 | 2 | |
| Rated surge voltage | 2.5KV | 2.5KV | 2.5KV | |
| Rated voltage | 160V | 160V | 250V | |
| Rated current | 8A | 8A | 8A | |
| UL Rated data | ||||
| Use geoup | B | C | D | |
| Rated voltage | 150V | – | – | |
| Rated current | 8A | – | – | |
| Wire range | AWG24-16 | |||
| Other information | ||||
| Housing | PA66 | |||
| Contact | Copper Alloy | |||
| Contact Coating | Sn plated | |||
| Screw | – | – | ||
| Rated torque | – | – | ||
| Flame retardant rating | UL94-V0 | |||
| Operating temperature | –40℃~+105℃ | |||
| Approval | UL CE | |||
Company Information
FAQ
Q1.Where is your company?
A1.Our company locates in No.625 Xingzhen Street ,Kandun , Cixi City , Zhejiang ,China . It cost 2 hours by car from here to Shanghai Pudong airport.
Q2.How is your lead time of female Connector?
A2.We have strong production capacity . Our lead time is 3-10 working days since the confirmation of the order .The final exact lead time upon your order quantity.
Q3.How long will you reply after receiving the inquiry .
A3.We will reply our customer’s inquiry within 2 hours after we receive the inquiry.
Packaging & Shipping
