Автоматический деревянный Венецианский штамповочный
- Категория: Home Textile Product Machinery >>>
- Поставщик: Guangzhou,Stec,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 5950.23 $* | 6248.47 $* |
| Aug-17-2025 | 5900.60 $* | 6195.22 $* |
| Jul-17-2025 | 4950.70 $* | 5198.94 $* |
| Jun-17-2025 | 5800.47 $* | 6090.8 $* |
| May-17-2025 | 5050.31 $* | 5303.70 $* |
| Apr-17-2025 | 5700.89 $* | 5985.8 $* |
| Mar-17-2025 | 5650.98 $* | 5933.78 $* |
| Feb-17-2025 | 5600.2 $* | 5880.92 $* |
| Jan-17-2025 | 5550.2 $* | 5828.4 $* |
Характеристики
AUTOMATIC WOODEN VENETIAN BLIND
SLAT PUNCHING MACHINE
Specifications
Automatic Wooden Venetian Blind Slat Feeding Punching Machine | |
Voltage | 110/220V AC 50/60HZ |
Rate power | 1.5KW |
Working air pressure | 0.4~0.5PMA |
Production rate | 30 slats/min |
Max slat length | 2600mm or customized |
Punching mold | 5pcs |
Slat collector | 1pc (included) |
Dimension | L3100mm*W770mm*H1580mm |
Packing size | 3200mm*820mm*1200mm |
N.W | 600KG |
G.W | 650KG |
Package | Steel frame with poly wood board cover |
Function features
1. High proformance PLC controlling system;
2. Automatic control mode and manual adjust setting mode control panel;
3. New design of double-rods slat pushing punching station to improve machine movement more smooth and stable;
4. Adopt new type motor to reduce energy consumption and noise.
5. Max slat punching slat length: 2600mm or customized
6. Available slat width: 25mm, 35mm, 50mm, 63mm(standard is equiqqed one size mold )
7.Molds are processed by best WEDM-LS ,and dualable.
Applications
Packaging & Shipping
Machine package is steel frame with poly wood cover board(no wood included) in order to make sure machine is in good condition when it arrive to customer's location.
