Фрезерный станок хобби с ЧПУ XH7125, фрезерный станок с ЧПУ
US $14900-$15300
Вертикальный Станок с ЧПУ серии
- Категория: Machine Centre >>>
- Поставщик: Jiangsu,Dongqing,Cnc,Machine,Tool,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 60690.91 $* | 63725.56 $* |
| Aug-16-2025 | 60180.57 $* | 63189.52 $* |
| Jul-16-2025 | 50490.57 $* | 53015.79 $* |
| Jun-16-2025 | 59160.18 $* | 62118.44 $* |
| May-16-2025 | 51510.59 $* | 54086.92 $* |
| Apr-16-2025 | 58140.95 $* | 61047.72 $* |
| Mar-16-2025 | 57630.50 $* | 60512.49 $* |
| Feb-16-2025 | 57120.47 $* | 59976.0 $* |
| Jan-16-2025 | 56610.11 $* | 59441.57 $* |
Характеристики
Model | Unit | XH714 |
| Travel for X/Y/Z axes | mm | 650/400/480 |
| Distance from spindle nose to table surface | mm | 80-560 |
| Distance from spindle center to column surface | mm | 480 |
| Worktable (length×width) | mm | 800*420 |
| Maximum load of table | Kg | 600 |
| T-slot (slot width×number of slot×pitch) | mm | 18*3*135 |
| Spindle speed | rpm | 60-8000 |
| Tool holder(model/ diameter) | BT40/φ150 | |
| Drive manner of spindle | Belt drive | |
| Motor power of spindle | Kw | 7.5(30min) |
| CNC system | FANUC/ Mitsubishi / Siemens | |
| Guide screw of X,Y axis | mm | 3206 |
| Guide screw of Z axis | mm | 3206 |
| Drive connection way | Direct connection | |
| Rapid shift of axes of X&Y/Z | m/min | 16/24 |
| Max. cutting feed speed | mm/min | 5-5000 |
| Motor power of three axes | Kw | 1.8 |
| Standard tool quantity | 16 | |
| Max. tool diameter / length | mm | Disc style:φ78/250, Hats-style:φ90/300 |
| Max. tool diameter | mm | φ120 |
| Max. tool weight | Kg | 7,8 |
| Tool exchanging manner | Pneumatic | |
| Clamping and loosening of tool | Automatic ( 4 claws) | |
| Average tool exchanging time | Sec | Disc style:2-3, Hats style:6-8 |
| Positioning accuracy | mm | meet with GB/T8771.4-1998 standard |
| Accuracy of repeated positioning | mm | meet with GB/T8771.4-1998 standard |
| Quantity of power supply needed | KVA | 16 |
| Power supply | 3N-380V/50Hz | |
| Requirement for air compressing | Kg/cm² | ≥6 |
| Air supply slow | m3/min | ≥0.5 |
| Machine weight | t | 3.8 |
| Overall dimension (length×width×height) | mm | 2330*2180*2350 |
Company Information
Founded in 1958 and developed more than half a century, Jiangsu Dongqing CNC Machine Tool CO. Ltd., has now became a forge ahead modern enterprise for production of CNC machine.
The R&D, production and marketing are the main component of the company. As shown on the website, the main product of the company covers five series, CNC milling machine & vertical machining center, CNC engraving machine, CNC wire cut EDM, Die sinking EDM and Micro hole drilling EDM.
The company has always engaged in improving the quality, function and performance of CNC machine in the past several years. It has successfully passed identification of ISO, CE, SGS, TUV & Bureau. “Innovation, development and win-win situation” makes TOPSCNC enjoy high reputation in this line.
TOPSCNC people wish to share success with you in the future!
TOPSCNC Customer
Certificates
Our service
1) Quality : We take care of the product quality in order to provide good service to our customers.
2)Warranty: One year after shipment,consumables are not included.
3)The quotation do not include installation and education training fee.
4)Engineers available to overseas repair service.
5) Payment Method: T/T or L/C at sight
6) Delivery time : 18--25 days
7) Packing : Standard export wooden cases
8)Port: Shanghai.
