Характеристики
SRCC Vacuum Tube Collector with Supper Heat Pipe SR30-58/1800
Solar Collector, Vacuum Tube Solar Collector, Vacuum Tube Collector, Solar Thermal Collector
1. Separated Pressure Solar Collector with Highly efficient absorber of high performance with daily average efficiency over 50%2. Start up quickly, heat pipe transfer the heat energy into the storage tank in one direction It can withstand pressure of tap water when it works
3. There is no need to wait with Separate Pressure Heat Pipe Solar Collector
4. Completely automatic operation Separated Pressure Solar Collector
5. Drinking water quality to promote life quality
6. Simple structure, easy to assembly and install, diffuse flat plate reflector can be assembled easily with its module structure
7. Temperature preservation can last for 80 hours
8. Without volatile tubes
9. Without incrusting, long usage life
| Model name | SR10-58/1800 | SR15-58/1800 | SR20-58/1800 | SR30-58-1800 |
| number of tubes | 10 | 15 | 20 | 30 |
| Dimensions mm | 1070*2020 | 1295*2020 | 1670*2020 | 2420*2020 |
| aperture area M2 | 0.94 | 1.403 | 1.88 | 2.806 |
| Aperture Efficiency | 0.735 | |||
| Absorber Area M2 | 0.82 | 1.224 | 1.64 | 2.448 |
| Absorber Efficiency | 0.842 | |||
| Flow Capacity (Liter) | 0.66 | 0.99 | 1.33 | 1.97 |
| working pressure | 6 bar | |||
| Max testing pressure | 12 bar | |||
| Max working temperature | 280°C | |||
| certificate | EN12975-1,2 SOLAR KEYMARK, SRCC | |||
| Material | ||||
| vacuum tube | high borosilicate glass | |||
| size | 58*1800mm | |||
| coating | SS-CU-AIN/ALN | |||
| heat pipe material | TU1 copper | |||
| heat pipe length | 1790mm | |||
| heat pipe diameter | condenser dia24mm, body dia 8mm | |||
| manifold header pipe | TP2 copper dia 42mm | |||
| manifold casing | anodized aluminum alloy | |||
| insulation | glass fiber | |||
| bracket | aluminum alloy | |||
| inlet/outlet connection | 22mm | |||
| Heat transfer medium | pure water/glycol | |||
| tube holder | UV stabilized nylon | |||
| seals | silicon seal | |||
| contact sheets | aluminum fin | |||
| Packing | ||||
| manifold size mm | 1*2000*200*180 | 1*2000*200*180 | 1*2000*200*180 | 1*2480*200*180 |
| tubes size mm | 1*1930*350*180 | 1*1930*350*250 | 2*1930*350*180 | 2*1930*350*250 |
| Qty (set) | 150/20' ft | 120/20' ft | 92/20' ft | 62/20' ft |
| 358/40' hq | 285/40' hq | 220/40' hq | 153/40' hq | |
