Onion Planter Machine

Model	LG-11
Dimension(mm)	1000*1200*650
Weight of the Machine	250kg
The width of sowing width	1300mm
sowing linage	8-20 linage
Power of the Tractor	18-30HP,220v









As shown in figure :

(1) before the press roller, bending flat tube opener after (2), (3) after the press roller(4)Roller scraper device before, (5) before the roller pressure adjustment lever, roller scraper device after (6), (7) vaccination funnel and grain tube, precision metering device (8), (9) deceleration, sprocket chain group (10) frame, the seed box (11), (12) and tractor hitch mechanism.



Detailed information:

Seeder three-point hitch mechanism (12) and tractor hydraulic suspension mechanism through the pin to hook up, make the machine to lift, move forward. Seeder roller diameter is 280 mm, before and after the row of kind of shaft rotational power by the back roller driven by gear chain sprocket through transfer of its rotation, front roller pressure flat to the ground, furrowing seeding, roller pressure again after soil buried seeds, make the ground flat, soil compaction, favorable quantity emergence.

Sowing depth adjustment can be made before the press roll adjusting rod (5) and roller adjustment rod (3) after adjustment, also can adjust the opener (2) the height adjustment. Spacing adjustment assembly screw loosening opener, move to the need to position, adjust depth, and then tighten and reduce the number of rows when remove opener, the corresponding redundant device for sealing up, make its can't row.for reference only, because of seed size are different), such large planting sugar beet seed, the insert arc plate all pull out.
