• Compact fluorescent lamp • Television receiver • Radio cassette player • PC power supply • Monitor,audio,VCD,DCD • UPS • The electronic apparatus • The noise rejection • Induction cooker,etc.
Specification
• High current capacity • Low core loss at frequency • High reliability, efficiency • Small packaged size • Operating Temperature: -30°C to +80°C • Electrical Specifications at 20°C
Specification Details
ELECTRONICAL CHARACTERISTICS: 1. INDUCTANCE: L1-2 = 7. OmH土10% @1. 0KHZ, 0. 25V L2-3 = 8. 0mH土10% @1. 0KHZ, 0. 25V 2. DC RES ISTENCE:R1-2 = 18.0 ohms MAX @25° C R2-3 = 29.0 ohms MAX @25° C 3. RATED CURRENT: 60 mA
NOTES: 1. CORE: DR3W8*10 2. WIRE: φ0.10 2UEW 3.TUBE: 8. 0*13.5 PVC BLACK 4. EPOXY: G-9007 BLACK
Related Products
Company Profile
Why Choose Us
Exhibition and Certifications
Packaging and Shipping
FAQ
Q1. Are you trading company or manufacturer? A: We are factory.
Q2. How long is your delivery time? A: Generally it is 5-10 days if the goods are in stock, or it is 15-20 days after your order, if the goods are not in stock, it is according to quantity.
Q3. Your magnetic rubber inductance is better? A: Yes, rubber magnetic inductance is ferrite magnetic core, a coil around, after coating a layer of glue, have good shielding effect, it is not easy to produce noise,
Q4. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery.
Q5. How do you make our business long-term and good relationship? A: 1.We keep good quality and competitive price to ensure our customers benefit. 2. We respect every customer as our friend and we sincerely do business and make friends with them.
If you have any other questions please contact with us or leave a message, we will reply you ASAP.
