  TPQ-215    Labor Saving wood chipper machines with discount price



General introduction of the product:

1.This series of chipper can cut log ,branch,forestry slab,waste single board,bamboo,cotton straws and other non-wood fiber stem into chip of required specification ,which can be used as basic raw material of shaving board ,fiberboard,non-wood artificial board and papermaking pulp.



2. This series chipper with advanced structure,can cut raw material into high quality chips, and has a wide raw material adaptability. On the other hand it is convenient to operate and fix.



3. This series chipper is made of the following       parts:body,knife roller,the upper&lower feed material rollers,conveyer belt,hydraulic system and so on.



1) The body is welded by high strength steel plate, and it is the sustaining base of the whole machine.



2)Two to four fly-cutters are fixed on the knife roller by fly-cutter bolts which is made specially through pressure blade.The upper feed material roller assembly can move up and down within a certain scope by means of hydraulic system according to the different thickness of raw material.Qualified chips will drop through sieve hole and discharge from the bottom,those bigger’s will be cut again in the machine.



3) Hydraulic system :from the oil pump to oil cylinder , it can help to start the cover for changing blade,it can also lift the upper feed material soller assembly for adjusting the clearance between the cutter and bedknife,and disassembling board.when the machine need repairing.

 Technical parameters of the product:

Model	TPQ-215	TPQ-216	TPQ-218	TPQ-2113
Inlet (mm)	180*400	240*540	310*700	400*700
Blade	2	2	2	2
Rotate Speed	500	650	800	1300
Max Diameter (mm)	160	230	300	450
Chip size (mm)	25-35	25-35	25-35	25-35
Capacity (Ton)	3-4	7-8	8-15	15-30
Main Motor Power (kw)	45	55	110	200-250
Feed Roller Motor (kw)	2.2*2	3*1,4*1	4*1,5.5*1	7.5*2
Oil pump Motor (kw)	1.5*1	1.5*1	1.5*1	3*1
Weight (kg)	2990	4070	7000	11840
Size (mm)	1470*1550*970	1800*1900*1210	2200*2150*1500	3670*2517*2050
Conveyor motor power (kw)	3	3	3	3



Why choose us?

Tony is one of the largest manufacturers and service supplier of pellet mill, crushing machine and other necessary equipment in complete pellet plant, such as drying equipment, cooling equipment and packing machine, and so on in China. That is why we can offer you brand new products at extremely low prices.

For more information about the product, like the price, the payment terms, the delivery time, etc, please don’t hesitate to ask me, and I will give you the reply asap.



Looking forward to hearing from you!
