Processor

·  AMD GX-415GA Quad-Core APU with AMD Radeon HD 8330E (1.5 GHz)

Storage

32GB MLC mSATA SSD

Memory

·  System memory: 4 GB DDR3L 1600 MHz standard, up to 16 GB

Graphics

·  AMD GX-415GA Quad-Core APU with AMD Radeon HD 8330E (1.5 GHz)

Communication

·  10/100/1000 Gigabit Ethernet (RJ-45) (actual speeds may vary)

·  Broadcom 802.11 a/b/g/n Wi-Fi with dual internal antennas (optional)

·  Broadcom 802.11ac with dual internal antennas (optional)

·  HP 100 Mbps Mini PCIe SC Fiber NIC (factory-installed option)

Audio

·  Internal amplified speaker

·  1/8-inch mini jack out

·  Full 24-bit stereo

·  Up to 192kHz sample rate

·  1/8-inch mini jack microphone in

·  24-bit stereo

·  up to 192 kHz sample rate input audio line in and out connectors on rear panel.

Ports and connectors

·  Front:

o    2 USB 2.0

o    2 USB 3.0

o    1 Headphone

o    1 Microphone

·  Rear:

o    2 USB 2.0

o    2 DisplayPort 1.2

o    1 RJ45

o    1 Audio Line-in

o    1 Audio Line-Out

o    1PS/2 KB

o    1 PS/2 Mouse

o    1 Configurable Port= 1 Serial (Default) or Fiber NIC or VGA

o    Hidden: 2 USB 2.0

Power

65W worldwide auto-sensing 100-240 VAC 50-60Hz surge-tolerant power supply

Input devices

·  Standard keyboard

·  Optical mouse included (USB or PS/2)

Output

·  Internal amplified speaker

·  1/8-inch stereo mini jack (headphones, on front panel)

·  1/8-inch stereo mini jack (line out, on rear panel)

·  Full 24-bit stereo

·  Up to 192 kHz sample rate

Input

·  1/8-inch mini jack microphone (on front panel)

·  1/8-inch stereo mini jack (line in, on rear panel)

·  24-bit stereo

·  Up to 192 kHz sample rate

Audio CODECS with hardware acceleration support

·  MP3

·  AAC stereo & HE AAC

·  WMA stereo

Video CODECS with hardware acceleration support

·  MPEG-4 part 2 (DivX, Xvid)

·  MPEG-4 part 10 (H.264, AVC)

·  WMV 7/8/9/ VC-1 & ASF Demuxer

Connector

RJ-45

Data rates supported

·  10Gb

·  100Gb

·  1000Gb

Management

·  Wake on LAN (WOL)

·  PXE

·  TCP/IP with DNS and DHCP

HP Fast Ethernet Mini PCIe SC Fiber Network Interface Card (factory-installed option)

Adapter

Allied Telesis AT-27MINI Fast Ethernet Fiber PCI Express MINI Network Interface Card

Form factor

Custom-designed card plugs into PCI-Express Mini Card slot, and mounts into device bay inside HP t620 chassis

Management features

·  WMI

·  ACPI 2.0/w01

·  PXE 2.1 boot ROM

·  SNMP

Ethernet

·  IEEE 802.1p (Quality of Service)

·  IEEE 802.2 (LLC)

·  IEEE 802.3ac (MAC)

·  IEEE 802.3u (100Mbps)

·  IEEE 802.1as (Audio Bridging)

·  P802.1Qav

·  P802.1Qat (SRP)

·  1588-2000 (PTP)

Network controller

Broadcom BCM57762

Connectors

SC

Power consumption

2 W(typical)

Compliance

·  RoHS

·  UL

·  FCC/EN55022 Class A

·  TUV

·  EN55024

·  CE

·  C-TICK

·  VCCI

Efficiency

65 W

Voltage range

Worldwide auto-sensing 100 - 240 V ac

Line frequency

50 - 60 Hz

Standard chassis vertical orientation with stand (H x W x D)

240 x 220 x 40 mm (9.5 x 8.7 x 1.6 in)

Standard chassis with stand

1.36 kg (3 lb)

Operating system preinstalled¹

·  Microsoft Windows Embedded Standard 7E
