American standard 900A train rail ASCE 75 ASCE 85 ASCE 40 ASCE 60 steel rail for high speed railway

Hot Sale Products

Product Show

American standard 900A train rail ASCE 75 ASCE 85 ASCE 40 ASCE 60 steel rail for high speed railway













Product Description

 American standard 900A train rail ASCE 75 ASCE 85 ASCE 40 ASCE 60 steel rail for high speed railway



Standard	American Standard
Grade/Material	700/900A
Model Number	ASCE 25, ASCE 30, ASCE 40, ASCE 60, ASCE 75, ASCE 85, 90RA, 115RE and 136RE
Weight	Customized
Length	6m-25m,
Packing	Bundling
Fastening	We can supply Joint bar,Rail anchor,spike&bolt,and other OEM products
Technique	Hot Rolled
Application	Railway rail
OEM	Acceptable
Processing	Drill hole according to your requirement
Place of Origin	China
MOQ	10 tons



American Standard Steel Rail
Specification	Size				Unit Weight	Material	Length
	Head Width	Height	Bottom Width	Web Thickness	(kg/m)		(m)
	(mm)	(mm)	(mm)	(mm)
ASCE 25	38.1	69.85	69.85	7.54	12.4	700	6m-12m
ASCE 30	42.86	79.38	79.38	8.33	14.88	700	6m-12m
ASCE 40	47.62	88.9	88.9	9.92	19.84	700	6m-12m
ASCE 60	60.32	107.95	107.95	12.3	29.76	700	6m-12m
ASCE 75	62.71	122.24	122.24	13.49	37.2	900A/110	12m-25m
ASCE 85	65.09	131.76	131.76	14.29	42.17	900A/110	12m-25m
90RA	65.09	142.88	130.18	14.29	44.65	900A/110	12m-25m
115RE	69.09	168.28	139.7	15.88	56.9	900A/110	12m-25m
136RE	74.61	185.74	152.4	17.46	67.41	900A/110	12m-25m



American standard steel rail includes different specifications, such as ASCE 25, ASCE 30, ASCE 40, ASCE 60, ASCE 75, ASCE 85, 90RA, 115RE and 136RE. IMRISTEEL can manufacture light steel rail and heavy steel rail in the materials of 700 and 900A. We also supply you with the customized service. If you have any purchasing requirement, please feel free to contact us anytime.



Other Types of Steel Rails We Produce:



Varieties	Specifications	Steel grade	Standard
Rail for Railway	43kg/m,50kg/m	U71Mn,U75V,U76CrRE,U20Mn	TB/T2344 TB/T3276
	60kg/m,75kg/m
	UIC54/UIC60	900A	Agreement
	54E1/60E1	R260	EN13674-1
	115RE/136Re	SS	AREMA 2014
Switch Rail	50AT/60AT	U71Mn,U75V,U76CrRE	TB/T2635
Head Hardened Rail	50kg/m,60kg/m,75kg/m	U71Mn,U75V,U76CrRE	TB/T2344
	UIC54/UIC60	900A	Agreement
	54E1/60E1	R350HT	EN13674-1
Crane Rail	QU80/QU100/QU120	U71Mn	YB/T5055

We can supply the rails used for general speed railway track with 160km/h,high speed railway track with 250km/h and 350km/h and profile from 37kg/m-75kg/m according to customers’ requirements. At the same time,we can supply switch rail,crane rail,Z section,I beam,channel,H beam and and steel sheet pile,etc.

Application

 More than 50 percent high speed railway rails in China are produced by Baotou Steel.Heavy rails and light rails we produce are used in mining,railway and subway construction.

Advantages

1.After over sixty years’ endeavor,Baotou Steel has grown to be the world’s largest rare earth industry base and domestic vital steel industry base.

2.Baotou Steel has the largest iron ore in the northwest part of China.

3.At present, Baotou Steel’s production capacity of iron and steel products has reached to 16.5 million tons.

Its products have been sold to over 60 countries abroad.

4. At the same time, it is the world’s most capable high speed rail production base with world’s best equipments.

Customer Visit

Certificates



  Inner Mongolia Rational Industry Limited (IMRI) is a supplier of anti-corrosion coating and seamless steel pipes. We have two production lines for external anti-corrosion coating, one production line for internal coating and one production line for insulating tubes. We mainly engage in accessory processing for Baotou Steel. At the same time, IMRI is a distributor of Baotou Steel''s steel products. We have established a long-term strategic co-operation relationship with Baotou Steel.
   Core members of our team have more than 10 years'' experience in the field of anti-corrosion coating production as well as anti-corrosion equipment designing. They are familiar with the purchasing requirements on anti-corrosion coating and steel pipes from international major oil companies. They also have supply experience for such companies like SONATRACH, BP, OGDCL, MRC, OXY, PDVISA, OMAN, LUK OIL, SHELL, ITOCHU, and BASF, etc.
   IMRI specializes in the process of internal and external pipe-coating, including 3LPE, 3LPP, FBE, and insulating tubes, etc. Our company is a distributor of Inner Mongolia Baotou steel Union Co., Ltd. The main products are seamless pipes, gas cylinder tubes, oil casing, hydraulic pillar tubes, alloy tubes, steel plates, wire rod coils, shape steels, and rail steels, etc.
   Founded in 1954, Baotou Steel is one of the steel companies who has the most complete industrial chain in China. It can produce 17 million tons of steel per year. It is a large integrated enterprise with iron ore, rare-earth ore, smelting, casting, rolling, pipe processing, testing, researching and transportation.
   Baotou Steel is a seamless pipe manufacturer with the most complete varieties and specifications in China whose annual output is 1.8 million tons. There are 5 production lines for seamless pipes in Baotou Steel. Among these, 2 PQF production lines are the most advanced in the world, and 1 MPM two-roll continuous rolling automatic production line is included.
   Combining its own advantage of coating technology with Baotou Steel''s advantages of products diversification, excellent quality, and low cost, IMRI can really achieve one-stop supply of anti-corrosive steel pipes.
   Be diligent and do better than you expect.

Contact Us

We can provide OEM service.If you need any kind of the steel pipes for water, oil and gas transportation ,petroleum casing & tubing,railway rails,etc. please feel free to contact us.
