Product Description
Tractel bravo lever hoists
The bravo lever hoist is ideal for industrial and building/civil engineering applications.
This hoist is designed for pulling, lifting, positioning and adjusting loads in workshops and/or on building sites.
The bravo is a rugged, quality built hoist designed for reliable operations even in the toughest conditions.
A Versatile Lever Hoist
Bravo models, available from 500 to 12,000 lbs. (1 4 to 6 t), are suitable for a wide variety of lifting, pulling and tensioning applications: for lifting and lowering loads in manufacturing and assembly operations, removing engines, rigging and moving loads, applying tension to conveyor.
Operates in temperatures between -40 and 140°F (-40 and 60°C)
Meets or exceeds ANSI/ASME B30.21C, Manually Lever-Operated Hoist code
Load chain manufactured in accordance with ISO T
Reliable & Easy to Use
- Easy operation with simple controls
- Lightweight and portable
- Compact and low weight, very handy
- Excellent weight / capacity / size ratio
- Minimum effort to lift maximum load
| | | | |
|---|---|---|---|
Durable Material
| Premium 360° Swivel Hook
| Reliable Braking System
| Safety & Ease of Use
|
| | | |
|---|---|---|
| | | |
 |  |  |  |  |  | |
|---|---|---|---|---|---|---|
| Lever Hoist 0.25T | Lever Hoist 0.5T | Lever Hoist 0.75T | Lever Hoist 1.5T | Lever Hoist 3T | Lever Hoist 6T | |
| Load Capacity | 500 lbs. (250 kg) | 1,000 lbs. (500 kg) | 1,500 lbs. (750 kg) | 3,000 lbs. (1,500 kg) | 6,000 lbs. (3,000 kg) | 12,000 lbs. (6,000 kg) |
| Lengths available | 5 Feet | 5, 10, 15, 20, 30, 40 Feet | 5, 10, 15, 20, 30 Feet | 5, 10, 15, 20, 30, 40 Feet | 5, 10, 15, 20, 30 Feet | 5, 10, 15, 20, 30, 40 Feet |
| Number of falls | 1 | 1 | 1 | 1 | 1 | 2 |
| Effort on lever at capacity | 57 lbs. (26 kg) | 79 lbs. (36 kg) | 44 lbs. (20 kg) | 46 lbs. (21 kg) | 73 lbs. (33 kg) | 75 lbs. (34 kg) |
| Load chain size | 4 x 12 mm | 5 x 15 mm | 6 x 18 mm | 7 x 21 mm | 10 x 30 mm | 10 x 30 mm |
| 360° swivel hook with overload opening indicators | ||||||
| Load chain manufactured in accordance with ISO T |
