KSPOWER L SERIES – CONSTANT VOLTAGE
The L series LED Driver is one 30Watt 12Volt ultra slim SELV, Class 2, Class P, TYPE HL, 0-10V / 1-10V / TRIAC / Resistance / PWM dimmable LED driver compatible with most AC wall dimmer including Lutron, Leviton and most other household dimmers making it the perfect choice for tape lighting, tube lighting, linear lighting and multiple other commercial lighting applications.



The L series LED drivers is also available in a non-dimmable version.The UL cUL FCC CE ENEC GS Listed led driver aluminum enclosure is rated IP67 for indoor or outdoor installations and includes a separate input and output wiring compartment for clean and easy installation. The 24VDC LED driver transformer features hiccup mode, over current and short circuit protection, as well as an efficiency over >88% resulting in a low operating case temperature.



110v 230v 277v input electrical voltage 24v outdoor light spotlight switches module outlet transformer phase led driver dimmer

30W12V Waterproof IP67 LED Driver Ultra Slim Transformer Triac Phase-cut Dimming 12V 24V 36V 48V Output



Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use

Output Voltage: 12VDC, 24VDC, 36VDC, or 48VDC

Driver Type: CV Class P SELV PFC function

Enclosure: LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box

Dimming:  PWM, TRIAC, 0/1-10V or MLV / ELV Dimmable; Non-Dimmable Available

Environmental: Dry and Damp

IP Rating: IP67



Features:



• Ultra slim height to 24.5mm

• Wiring Compartments with Knock-Outs for Clean and Easy Installation

• Current Limiting Overload Protection

• Flicker-Free

• Smooth Ripple Free Output Voltage

• IP67 Rated Enclosure for Indoor and Outdoor Use

• 5-Years Warranty

• UL/cUL FCC CE ENEC GS Listed, SELV, Type HL



Wiring Drawing:



Dimension Drawing(mm):



Package:





Package	Piece/Carton(pcs)	Dimension/Carton(mm)	Dimension/Brown Box(mm)	Piece Weight(KG)	Gross Weight/Carton(KG)
OEM package	20	360 x 356 x 190	339 x 65 x 41	0.86	18
