Завод по производству цементного лайма вращающаяся печь полностью небольшая производственная линия
- Категория: Cement Making Machinery >>>
- Поставщик: Henan,Turui,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.89 $* | 0.11 $* |
| Aug-19-2025 | 0.14 $* | 0.21 $* |
| Jul-19-2025 | 0.62 $* | 0.95 $* |
| Jun-19-2025 | 0.55 $* | 0.8 $* |
| May-19-2025 | 0.92 $* | 0.58 $* |
| Apr-19-2025 | 0.79 $* | 0.68 $* |
| Mar-19-2025 | 0.55 $* | 0.60 $* |
| Feb-19-2025 | 0.9 $* | 0.7 $* |
| Jan-19-2025 | 0.14 $* | 0.45 $* |
Характеристики
Products Description
Cement Production Line Features
Cement production line is the production line construction project composed by a series of corollary equipments which are used for product cement.Our Satisfied Customer Return Ratio with the support of our skilled Cement Plant expert we are successfully installing cement plants in India, Middle Asia ,South America and South African countries.Great wall supply process design、civil construction、complete equipment、installation and trial run、technical services、the general contracting. Our complete production line are: 6000t/d cement production line、5000t/d cement production line、3000t/d cement production line、2500t/d cement production line, 1500t/d cement production line、500t/d cement production line、300 t/d cement production line construction.
Main Equipment
Working Flow
Technological
1.Crushing: during the process of cement production, most of the raw materials need to be crushed. Limestone is the largest amount raw material for cement production, so the limestone crushing has an important position at the material crushing in cement plants.
2.Pre-homogenization: Raw material pre-homogenization technology is achieving the raw material initial homogenize by scientific stacker and reclaimer technology during the storage and reclaimer process of raw materials, ensure that the raw material ground has the capability of storage and homogenize.
3.Raw materials homogenize: At the dry process of cement production, stabilize the raw material ingredient is the premise of clinker sintering, raw material homogenize system is used for stabilize the raw material ingredient inlet the kiln.
4.Preheat and decomposition: We use the preheater to finish the raw materials preheat, replace part of the capabilities of rotary kiln and reduce the length of rotary kiln. The materials finished heat gas exchanging inside the rotary kiln under the state of suspend and preheat.
5.The right of gas-solid separation: When the airflow with material powder get into cyclone, and were forced to do rotate flowing at the annulus space between cyclone barrel and inside barrel while doing downward movement.
6.The precalcining: Great wall precalciner technology is a technological leap of cement calcination process. It is added between the preheater and calciner kiln using kiln tail rise flue, set the fuel injected device, so that the process of carbonate endothermic exothermic decomposition of the fuel combustion process and raw materials, in the decomposition furnace to the suspended or fluidized state quickly, so that the decomposition rate of kiln feed is increased to 90%.
7.Sintering: After completion preheater and precalciner, next process is carried out into the clinker kiln firing. The carbonate rapidly resolved and occur a series of solid-phase reaction in rotary kiln to bring the mineral into. As the material temperature close, the liquid will become minerals dissolved in the liquid phase reaction and generates a large number. After the clinker burning, the temperature began to decrease. Finally, the cement/clinker cooler unloading the kiln cooler temperatures to the downstream transport, storage libraries and cement mill can withstand the temperatures of hot clinker while recovering sensible heat, improving system thermal efficiency and clinker quality.
2.Pre-homogenization: Raw material pre-homogenization technology is achieving the raw material initial homogenize by scientific stacker and reclaimer technology during the storage and reclaimer process of raw materials, ensure that the raw material ground has the capability of storage and homogenize.
3.Raw materials homogenize: At the dry process of cement production, stabilize the raw material ingredient is the premise of clinker sintering, raw material homogenize system is used for stabilize the raw material ingredient inlet the kiln.
4.Preheat and decomposition: We use the preheater to finish the raw materials preheat, replace part of the capabilities of rotary kiln and reduce the length of rotary kiln. The materials finished heat gas exchanging inside the rotary kiln under the state of suspend and preheat.
5.The right of gas-solid separation: When the airflow with material powder get into cyclone, and were forced to do rotate flowing at the annulus space between cyclone barrel and inside barrel while doing downward movement.
6.The precalcining: Great wall precalciner technology is a technological leap of cement calcination process. It is added between the preheater and calciner kiln using kiln tail rise flue, set the fuel injected device, so that the process of carbonate endothermic exothermic decomposition of the fuel combustion process and raw materials, in the decomposition furnace to the suspended or fluidized state quickly, so that the decomposition rate of kiln feed is increased to 90%.
7.Sintering: After completion preheater and precalciner, next process is carried out into the clinker kiln firing. The carbonate rapidly resolved and occur a series of solid-phase reaction in rotary kiln to bring the mineral into. As the material temperature close, the liquid will become minerals dissolved in the liquid phase reaction and generates a large number. After the clinker burning, the temperature began to decrease. Finally, the cement/clinker cooler unloading the kiln cooler temperatures to the downstream transport, storage libraries and cement mill can withstand the temperatures of hot clinker while recovering sensible heat, improving system thermal efficiency and clinker quality.
Product Paramenters
No. | Workshop name | Main equipment | Work plan | Quantity |
1 | Limestone crushing | Single-Stage Hammer Crusher Feeding size: <600mm Capacity: 120t/h Discharging size: 90% <25mm | 6d/w×7h/d | 1 |
2 | Mixed material crushing | High-Efficiency Crusher Feeding size: <215mm Capacity: 50t/h Discharging size: 90% <20mm | 1d/w×7h/d | 2 |
3 | Raw material grinding | Ball Mill Feeding size:≤25mm Finished fineness:Feeding moisture:≤ 8% Finished moisture:<1% Capacity: 50 t/h | 7d/w×20h/d | 1 |
4 | Clinker calcination | Rotary Kiln Heat consumption: ≤950kCal/kg Capacity: 800t/d(33.3t/h) Power: 220kW Fuel: gas | 7d/w×24h/d | 1 |
5 | Cement grinding | Cement Mill Feeding size:≤20mm Finished fineness:Capacity: 45 t/h PC32.5 Power: 1600kw | 7d/w×22h/d | 1 |
6 | Cement packing | Rotary Packing Machine Capacity: 100t/h With cement bulk machine | 6d/w×12h/d | 1 |
Product delivery
Project Cases
Cement Production Line of Xinxiang Huaxin Power Group Co., Ltd.
Project company: Xinxiang Huaxin Power Group Co., LTD
Project address: NO. 184, Baoshan Road, Fengquan District, Xinxiang City
Main engine: Φ3.2×13 m three-cabin clinker ball mill
Production capacity: unknown
Project address: NO. 184, Baoshan Road, Fengquan District, Xinxiang City
Main engine: Φ3.2×13 m three-cabin clinker ball mill
Production capacity: unknown
Company Profile
Henan Turui Machinery Co., Ltd is a professional manufacturer of different mining machinery. It integrates the design, research,production, sales and installation together, guaranteeing the reliable and stable quality.
Its main products includes calcining equipment, ore dressing equipment, crushing and screening equipment, drying and cooling equipment, and grinding equipment. There are more than hundred of customers using our products all over the world, such as in south-east Asia, south-Asia, middle Asia, middle-east area, Africa, Australia, South America. The company covers an area of 40,000 square meters, building area of 10,000 spare meters. There are more than forty sets of boring-milling machine, gear hobbling machine, vertical lathe, and travelling crane at the workshop.
Now the company has more than one hundred employees, including 8 professional engineers. Seventy-five percent of the employees have participated the professional technical training, which makes sure high-efficient pre-sales and after-sale service.
Its main products includes calcining equipment, ore dressing equipment, crushing and screening equipment, drying and cooling equipment, and grinding equipment. There are more than hundred of customers using our products all over the world, such as in south-east Asia, south-Asia, middle Asia, middle-east area, Africa, Australia, South America. The company covers an area of 40,000 square meters, building area of 10,000 spare meters. There are more than forty sets of boring-milling machine, gear hobbling machine, vertical lathe, and travelling crane at the workshop.
Now the company has more than one hundred employees, including 8 professional engineers. Seventy-five percent of the employees have participated the professional technical training, which makes sure high-efficient pre-sales and after-sale service.
Why Choose Us
Choosing a reliable supplier is halfway to a robust cement grinding plant. And Turui Machinery is the right supplier you are looking for.
1. 1.Turui can provide a custom-design solution to cement manufacturing for every client.
2. 2.Turui can provide perfect after-sales service, which covers equipment installation, operation, production, and maintenance. And we will send technicians for guidance and training until customers are satisfied.
3. 3.Turui can provide cement grinding plants at factory prices.
4. 4.Cement production starts up in three to six months.
5. 5.All types of cement are possible.
1. 1.Turui can provide a custom-design solution to cement manufacturing for every client.
2. 2.Turui can provide perfect after-sales service, which covers equipment installation, operation, production, and maintenance. And we will send technicians for guidance and training until customers are satisfied.
3. 3.Turui can provide cement grinding plants at factory prices.
4. 4.Cement production starts up in three to six months.
5. 5.All types of cement are possible.
