Новейший многофункциональный ЖК-дисплей подземный кабель локатор NF-826 провода детектор неисправностей с бесконтактная проверка напряжения
- Категория: Testing Equipment >>>
- Поставщик: Shenzhen,Noyafa,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 108.94 $* | 110.22 $* |
| Jul-15-2025 | 88.36 $* | 90.27 $* |
| Jun-15-2025 | 106.36 $* | 108.12 $* |
| May-15-2025 | 105.4 $* | 107.49 $* |
| Apr-15-2025 | 84.31 $* | 86.65 $* |
| Mar-15-2025 | 104.0 $* | 106.69 $* |
| Feb-15-2025 | 103.47 $* | 105.85 $* |
| Jan-15-2025 | 102.79 $* | 104.29 $* |
Характеристики
Products Description
Features:
Detecting cables, electrical lines-water/gas supply pipelines buried in wall or earth
Detecting interruptions and short circuit in cables and electrical lines buried in wall or earth
Detecting fuses and assigning current circuits.
Both transmitter and receiver display power level, code, battery, detected voltage type and value, and high-voltage alert.
Transmitter built in DC/AC voltage meter for linear measurement of 12-400V DC/AC voltage
Technical Index
Transmitter | LCD Screen | 52*35mmTN screen with backlight |
Key | silicon keys * 8 | |
Adjustable transmitter signal codes | 6 types | |
Adjustable transmitter signal amplitude | 3 degrees | |
transmitter signal frequency | 125KHz | |
Signal Vp-p | <=8V | |
transmitter self-inspection | Yes | |
Circuit voltage testing | AC:12~400V(50~60Hz)+/-2.5% DC:12~400V +/-2.5% | |
Buzzer | √ | |
Mute | √ | |
Lamp | √ | |
LCD backlight | on/off | |
Interface type | multimeter jack | |
Power supply | 3.7V 1400mAh Lithium battary | |
battary indicator | √ | |
Charging voltage | DC5V | |
Charging current | <600mA | |
Receiver | LCD Screen | 52*35mmTN screen with backlight |
Key | silicon keys * 8 | |
Accpetable transmitter signal codes | 6 types | |
Acceptable transmitter signal amplitude | 3 degrees | |
Received signal strength display | √ | |
recognize low battary warning of transmitter | √ | |
Received signal frequency | 125KHz | |
Max reception range | <=60cm | |
Short circuit detection | √ | |
open circuit detection | √ | |
Automatic frequency sweep | √ | |
Reception mode | Manual / Auto | |
NCV function | AC:50~400V(50~60Hz)+/-2.5% | |
Buzzer | √ | |
Mute | √ | |
Lamp | √ | |
LCD backlight | on/off | |
Power supply | 3.7V 1400mAh Lithium battary | |
Battary indicator | √ | |
Charging voltage | DC5V | |
Charging current | <600mA | |
Auto-off time | 10 mins |
