F-16KSH-N двойной гофрированный потенциометр
- Категория: Потенциометры >>>
- Поставщик: Yueqing,Omter,Electronic,&,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.28 $* | 0.3 $* |
| Aug-17-2025 | 0.21 $* | 0.67 $* |
| Jul-17-2025 | 0.36 $* | 0.53 $* |
| Jun-17-2025 | 0.10 $* | 0.26 $* |
| May-17-2025 | 0.74 $* | 0.94 $* |
| Apr-17-2025 | 0.96 $* | 0.53 $* |
| Mar-17-2025 | 0.41 $* | 0.40 $* |
| Feb-17-2025 | 0.59 $* | 0.82 $* |
| Jan-17-2025 | 0.16 $* | 0.10 $* |
Характеристики
General Specification
MAIN SPECIFICATION | ||
Total Resistance | 500Ω- 1MKΩ | |
Total Resistance tolerance | ±20% | |
Resistance Tape | A,B,C,D | |
Max. operation voltage | Linear B:AC200V;Other :AC 150V | |
Power Rate | Single unit linear B:0.2W Other Tapers:0.1W | |
Dual unit linear B:0.125W;other:0.06W | ||
Withstanding voltage | 1minute at AC 500V | |
Noise | Less than 100mV | |
Insulation resistance | more than 100mΩ at DC500V | |
Residual Resistance Value | Term.1~2: Less than 20Ω | |
Term.2~3: Less than 20Ω | ||
Tracking error | -40dB~0dB±3dB | |
Switch return route | S.P.S.T. | |
Switch contact resistance | Less than 50 mΩ | |
Switch power rate | Single unit 1.0A at AC/DC 12V | |
Dual Unit 2.0A at AC/DC 125v | ||
Total Rotation Angle | 300±5(degree) | |
Rotation Torque | 20~200 gf.cm | |
Shaft Stop Strength | 7.0Kgf.cm Min | |
push-pull strength | 8.0kgf Min | |
Switch rotation angle | 35±10(degree) | |
Switch torque | 150~500 gf.cm | |
...
