Цифровой 15 мм умный Modbus водомер DN15 беспроводной Lorawan Ультразвуковой счетчик воды с дистанционным
- Категория: Testing Instrument & Equipment >>>
- Поставщик: Kaifeng,Xintai,Valve,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 45.2 $* | 47.28 $* |
| Aug-19-2025 | 45.60 $* | 47.68 $* |
| Jul-19-2025 | 38.57 $* | 40.60 $* |
| Jun-19-2025 | 44.77 $* | 46.59 $* |
| May-19-2025 | 38.56 $* | 40.98 $* |
| Apr-19-2025 | 43.61 $* | 45.67 $* |
| Mar-19-2025 | 43.88 $* | 45.10 $* |
| Feb-19-2025 | 43.40 $* | 45.55 $* |
| Jan-19-2025 | 42.28 $* | 44.52 $* |
Характеристики
Product Description
Specification
Nominal Caliber | Common Flow | Transitional Flow | Min Flow | Flow Sensor Interface Size | Flow Sensor Connection Size | Case L | ||||||
DN mm | Q3 m³/h | Q2 m³/h | Q1 m³/h | Thread L mm | Thread Size | Connection L mm | Thread L mm | Thread Standard | mm | |||
15 | 2.5 | .0.016 | 0.01 | 10 | G3/4 | 43 | 15 | R1/2 | 165 | |||
20 | 4 | 0.025 | 0.016 | 12 | G1B | 50 | 16 | R3/4 | 195 | |||
25 | 6.3 | 0.04 | 0.025 | 12 | G1 1/4B | 58 | 18 | R1 | 225 | |||
32 | 10 | 0.064 | 0.04 | 13 | G1 1/2B | 58 | 20 | R1/4 | 180 | |||
40 | 16 | 0.1 | 0.064 | 13 | G2B | 59 | 22 | R1/2 | 200 | |||
Features
(1) Range Ratio: Default R250 (R125/R160/R200/R400 customized)
(2) Pressure Class: MAP16
(3) Max Pressure Loss: ≤0.040Mpa
(4) Temperature Class: T30
(5) Protection Level: IP68
(6) Environment Class: B Level ( O optional)
(7) Electromagnetic environment and other levels:E1
(8) Flow Field Sensitivity: U5/D3
(9) Data Storage: 24 months historical data, alarm occurrence time and alarm source
(10) Pipe Material: Copper
(11) Communication: LoRaWAN, (NB-IoT, M-BUS,RS485 OPTIONAL)
(12) IoT networking: LoRaWAN, Supporting and perfect operation management system platform
(13) Installation: H/V
(2) Pressure Class: MAP16
(3) Max Pressure Loss: ≤0.040Mpa
(4) Temperature Class: T30
(5) Protection Level: IP68
(6) Environment Class: B Level ( O optional)
(7) Electromagnetic environment and other levels:E1
(8) Flow Field Sensitivity: U5/D3
(9) Data Storage: 24 months historical data, alarm occurrence time and alarm source
(10) Pipe Material: Copper
(11) Communication: LoRaWAN, (NB-IoT, M-BUS,RS485 OPTIONAL)
(12) IoT networking: LoRaWAN, Supporting and perfect operation management system platform
(13) Installation: H/V
(14) Low overall power consumption, the built-in lithium battery last for 10 years
(15) Very low initial flow, can achieve drip metering
(16) Ability of forward and reverse measurement
(17) 4 high-speed measurements per second
(18) With self-diagnosis function: flow sensor failure alarm, measurement over-range alarm, battery under-voltage alarm
(15) Very low initial flow, can achieve drip metering
(16) Ability of forward and reverse measurement
(17) 4 high-speed measurements per second
(18) With self-diagnosis function: flow sensor failure alarm, measurement over-range alarm, battery under-voltage alarm
Company Profile
Certifications
Packing & Delivery
Installation Site
FAQ
Q1: Can I get free samples?
A: Yes, we can provide you with free samples, but you have to bear the delivery costs
Q2: Can your company print our brand logo on your products?
A: With the customer's permission, our factory can print the customer logo on the product. However, the customer needs to provide us with a logo authorization so that we can print the customer logo on the product.
Q3: What are your quality control procedures?
A: We adhere to strict quality control procedures, from product design to the end of the production process, using the most advanced quality control equipment, so that all processes are always in the best state of control.
Q4: Can I request a change in packaging and shipping?
A: Yes, we can change the packing and shipping method according to your requirements, but the cost and difference incurred in the meantime will be your responsibility.
Q5: What are your payment terms?
A: T/T, L/C, Alibaba Trade guarantee is available to provide full protection for your orders.
Q6: What is the standard lead time for each order?
A: It depends on the number of orders you need to purchase. Normally, we complete the order within 15 days.
A: Yes, we can provide you with free samples, but you have to bear the delivery costs
Q2: Can your company print our brand logo on your products?
A: With the customer's permission, our factory can print the customer logo on the product. However, the customer needs to provide us with a logo authorization so that we can print the customer logo on the product.
Q3: What are your quality control procedures?
A: We adhere to strict quality control procedures, from product design to the end of the production process, using the most advanced quality control equipment, so that all processes are always in the best state of control.
Q4: Can I request a change in packaging and shipping?
A: Yes, we can change the packing and shipping method according to your requirements, but the cost and difference incurred in the meantime will be your responsibility.
Q5: What are your payment terms?
A: T/T, L/C, Alibaba Trade guarantee is available to provide full protection for your orders.
Q6: What is the standard lead time for each order?
A: It depends on the number of orders you need to purchase. Normally, we complete the order within 15 days.
