L3 managed 8 port Gigabit / 10G Uplink SFP+ Port  Smart  Network industrial Managed ethernet Fiber Switch



Description

The OFS-MXF8-3 series is a high performance 8-port industrial managed 1G/10G Ethernet switch with 8 1G/10G SFP+ ports. The switch supports STP/RSTP/MSTP. It also supports web-based network management, VLAN, QoS, SNMP , IGMP snooping and other network functions. LED indicators provide connection status when using the SFP option. Suitable for many applications such as intelligent transportation systems, IP surveillance and industrial networks. The rugged design with industrial level 3 ESD protection makes it suitable for many applications such as intelligent transportation systems, IP surveillance and industrial networks. This product is available in a mounting ear configuration.This product is available in a mounting ear configuration.



8× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices, and provide up to 160 Gbps of switching capacity.Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS, Server, 10G PCIe Adapter/ NIC, gaming computer, 10G WiFi 6 AP, 8K video, and more.Ideal for Various Scenarios. Built for lightning-fast connections in business and home offices, workstations, LAN parties, and home entertainment.



Features



 8* 1G/10G SFP+ Ethernet ports

 STP / RSTP / MSTP redundancy protocols and standards

 SNMPv1/v2c/v3 & RMON & Port base/802.1Q VLAN network management IGMP Snooping multicast function

 Support ARP/RIP/OSPF/OSPFV3/BGP/Router Discovery/VRRP/ Route-Map/BFD three-layer routing

 WEB, Telnet, SSH, Console (CLI)

 open and close port, binding MAC and port 802.1x network access control

 802.1Q protocol, Isolate network flow Radius Centralized password management

 Overcurrent protection and reverse polarity protection

 Unique DIN mount design makes mounting and removal simple

 Built-in 12V lead-acid battery charging circuit (optional).



Technical parameter list

IEEE Ethernet Standards	IEEE802.3, IEEE802.3u, IEEE 802.1ab,IEEE802.3z, IEEE 802.3x, IEEE 802.3ad,IEEE 802.1d, IEEE 802.1p, IEEE 802.1q,IEEE 802.1w, IEEE 802.1s, IEEE 802.1x,IEEE 802.1ab ,IEEE 802.3ae 10G Base LR/SR
10G  1G/SFP+	8
Architecture	Store-and-forward
Bandwidth	160Gbps
Buffer	120Mbps
Mac Address Table	16K
VLAN	4K VLAN; Port-based VLAN; 802.1Q VLAN protocol;
Port configuration	Port enable/disable; Port rate settings Full-duplex mode; Flow control;
Multicasting	SNMP V1/V2/V3 protocols; IGMP Snooping; IGMP multicast group:1024
Console Port	RJ45
Dimension (L*W*H)	250*150*44mm
net weight	1.1kg
Security Feature	Enable/disable ports MAC based port security Port based network access control VLAN (802.1Q) Radius centralized password management SNMP v1/v2c/v3 encrypted authentication and access security
Protocols	STP/RSTP/MSTP, SNTP, 1588 PTP DHCP Server/Client, MVR, IGMP v1/v2 GMRP, GVRP, SNMP v1/v2c/v3, TFTP, SMTP,RMON, RARP, HTTP, HTTPS, Telnet,SSH, Syslog LLDP, IPv6, NTP Server/Client ARP/RIP/OSPF/OSPFV3/BGP/VRRP/BFD
Warning & Monitoring	Relay output for fault event alarming Syslog to record and view events Event selection support
Power	DC12V
Operating Temperature	-40 ~ +50Degree
Storage Temperature	-40 ~ +80Degree
Operating humidity	5%~80% non-condensing
Surge	6KV, IEC61000-4-5
ESD	ESD Level 4: IEC61000-4-2 RS Level 3: IEC61000-4-3 EFT Level 4: IEC61000-4-4 CS Level 3: IEC61000-4-6



Ordering Information

OFS-MXF8-3

8*1G/10G optical port, web management, CLI command line, L3,external power supply.
