ONETHINGCAM новая модель 2U сервер PR260CX поддержка 8*3 5/2 5 дюймов горячий подключение жестких дисков и

item

value

Certification

FCC, ce

Type

Rack

Processor Main Frequency

3GHz

Processor Type

2nd generation Xeon CPU

Brand Name

ONETHINGCAM

Model Number

260CX-3

Place of Origin

China,Guangdong

Form factor

2U rack

Number of processors

1/2pc

Processor Model

1 x 2nd Generation Intel® Xeon® Scalable Processor

Memory

8 x DDR4 DIMM slots, supports RDIMM of 2933MHz, 1TB Max

Hard Disk

Front:
Up to 8 x 3.5-inch or 2.5-inch hot-plug SAS/SATA/SSD
Internal:
1 x PCI-E M.2 SSD
Rear:
Up to 2 x 2.5-inch hot- plug SAS/SATA/SSD, or 2 x 2.5-inch U.2 SSD

Raid Support

Supports SATA RAID 0，1，10，5
Optional: supports SAS RAID 0, 10, 5, 50, 6, 60, etc., RAID(non-cache)/ 1GB/2GB(cache)
Optional: power-down protection for cache data

Network Interface

Integrated 2 * gigabit GE ports; optional: external GE & 10 gigabit network cards or gigabit OCP module

PCIE Expansion

By default, provides 5 * PCI-E Gen3 slots and 1 * OCP Type A/C special slot.
Slot 0: 1 x16 slot PCIe Gen3 for LP from CPU1 (default);
Slot 1: 1 x16 slot PCIe Gen3 for LP from CPU1 (default);
Slot 2: 1 x16 slot PCIe Gen3 for LP from CPU1 (default); supports PCI card with 1 x16 slot PCIe Gen3 for FH, double wide
(optional)
Slot 3: 1 x8 slot PCIe Gen3 for LP from CPU1 (default); this slot is not available while adding PCI card to slot 2;
Slot 4: 1 x16 slot PCIe Gen3 for LP from CPU0 (default), supports PCI card with 1 x16 slot PCIe Gen3 for FH, double wide
(optional)

Other Ports

Front Ports: 2 x USB 3.0
Rear Ports: 2 x USB 2.0
1 x VGA
1 x management network port
Internal Ports: 1 x USB 3.0

Fans

3 x hot-plug fans

Power Supply

Standard:1 X 550 W Platinum power supply(AC);
Supports 1 + 0 single power supply, or 1 + 1 redundant power supply; Optional: 550W/800W/1200W Platinum power module(AC)

Management

Supports IPMI2.0, provides 1100-Mbps or 1000-Mbps RJ45 management network port, and integrated iKVM, supports remote management

Display Controller

Integrated ASPEED AST2500

CD-ROM/Floppy Drive

Optional: SATA/USB drives

Supported Operating Systems

Windows Server 2012 R2
Red Hat* Enterprise Advanced Server 7.5

Power Supply

220V AC /240V DC

Physical Size

Height–87 mm (3.4 inches) * Width–438 mm (17.24 inches) * Depth –660 mm (25.98 inches), support racks with 19 inch, minimum
weight (with the standard configurations) is about 17kg (37.5 lb).

Environment and Specification

Ambient Temperature

10–35°C (50–95°F) while operating;
-40 - 55 ° C(-40 - 135 ° F) while in storage, according to the surroundings.

Relative Humidity

95% RH while in storage, non-condensing between 25 and 30 °C

Noise

While operating, the sound pressure is less than50dBA in the lateral position; while idle, the sound intensity is 6.2BA at
ambient temperature <28°C

Electrostatic discharge

Each Intel Environmental Temperature Test Specification is 15KV

Safety standards

CCC
